Description

The Volatility Framework is a completely open collection of tools, implemented in Python under the GNU General Public License, for the extraction of digital artifacts from volatile memory (RAM) samples. The extraction techniques are performed completely independent of the system being investigated but offer visibility into the runtime state of the system. The framework is intended to introduce people to the techniques and complexities associated with extracting digital artifacts from volatile memory samples and provide a platform for further work into this exciting area of research.

The official documentation is very complete and is available here: http://code.google.com/p/volatility/wiki/VolatilityIntroduction?tm=6

Plugins are grouped into following categories:

Windows Core
Identification
Processes
and DLLs
Process
Memory
Kernel Memory
and Objects
Networking Registry Crash Dumps, Hibernation
and Conversion
Miscellaneous
Windows GUI
Windows Malwares

Installation

$ cd /data/src/
$ wget https://www.volatilesystems.com/volatility/2.1/volatility-2.1.tar.gz
$ tar xzvf volatility-2.1.tar.gz
$ cd volatility-2.1/
$ python vol.py --help
Note
Specific python bindings are required by some plugins. They are specified in the "Required" section of each plugin.

Usage

Syntax

General usage:

python vol.py plugin options

Help on a given plugin:

python vol.py plugin -h

Example:

$ python vol.py yarascan -h
Volatile Systems Volatility Framework 2.2
Usage: Volatility - A memory forensics analysis platform.

[REMOVED]

  -Y YARA_RULES, --yara-rules=YARA_RULES
                        Yara rules (as a string)
  -y YARA_FILE, --yara-file=YARA_FILE
                        Yara rules (rules file)
  -D DUMP_DIR, --dump-dir=DUMP_DIR
                        Directory in which to dump the files

---------------------------------
Module YaraScan
---------------------------------
Scan process or kernel memory with Yara signatures

Environment variables

You can define some environment variables (VOLATILITY_PROFILE, VOLATILITY_LOCATION) prior to calling volatility in order to save time. Here is an example:

$ export VOLATILITY_PROFILE=Win7SP0x86
$ export VOLATILITY_LOCATION=file:///tmp/myimage.img
$ ./vol.py pslist
$ ./vol.py files

Options

-h, --help
list all available options and their default values.
Default values may be set in the configuration file (/etc/volatilityrc)
--conf-file=.volatilityrc
User based configuration file
-d, --debug
Debug volatility
--plugins=PLUGINS
Additional plugin directories to use (colon separated)
--info
Print information about all registered objects
--cache-directory=~/.cache/volatility
Directory where cache files are stored
--cache
Use caching
--tz=TZ
Sets the timezone for displaying timestamps
-f FILENAME, --filename=FILENAME
Filename to use when opening an image
--profile=WinXPSP2x86
Name of the profile to load. Supported profiles are:
  • VistaSP0x64 (Windows Vista SP0 x64)
  • VistaSP0x86 (Windows Vista SP0 x86)
  • VistaSP1x64 (Windows Vista SP1 x64)
  • VistaSP1x86 (Windows Vista SP1 x86)
  • VistaSP2x64 (Windows Vista SP2 x64)
  • VistaSP2x86 (Windows Vista SP2 x86)
  • Win2003SP0x86 (Windows 2003 SP0 x86)
  • Win2003SP1x64 (Windows 2003 SP1 x64)
  • Win2003SP1x86 (Windows 2003 SP1 x86)
  • Win2003SP2x64 (Windows 2003 SP2 x64)
  • Win2003SP2x86 (Windows 2003 SP2 x86)
  • Win2008R2SP0x64 (Windows 2008 R2 SP0 x64)
  • Win2008R2SP1x64 (Windows 2008 R2 SP1 x64)
  • Win2008SP1x64 (Windows 2008 SP1 x64)
  • Win2008SP1x86 (Windows 2008 SP1 x86)
  • Win2008SP2x64 (Windows 2008 SP2 x64)
  • Win2008SP2x86 (Windows 2008 SP2 x86)
  • Win7SP0x64 (Windows 7 SP0 x64)
  • Win7SP0x86 (Windows 7 SP0 x86)
  • Win7SP1x64 (Windows 7 SP1 x64)
  • Win7SP1x86 (Windows 7 SP1 x86)
  • WinXPSP1x64 (Windows XP SP1 x64)
  • WinXPSP2x64 (Windows XP SP2 x64)
  • WinXPSP2x86 (Windows XP SP2 x86)
  • WinXPSP3x86 (Windows XP SP3 x86)
-l LOCATION, --location=LOCATION
A URN location from which to load an address space
-w, --write
Enable write support
--use-old-as
Use the legacy address spaces
--dtb=DTB
DTB Address
--cache-dtb
Cache virtual to physical mappings
--output=text
Output in this format (format support is module specific)
--output-file=OUTPUT_FILE
write output in this file
-v, --verbose
Verbose information
-k KPCR, --kpcr=KPCR
Specify a specific KPCR address
-g KDBG, --kdbg=KDBG
Specify a specific KDBG virtual address

Supported Plugin Commands

For a more detailed document, go here: http://code.google.com/p/volatility/wiki/CommandReference

apihooks

Description
Detect API hooks in process and kernel memory
Requires
Install distorm3 code.google.com/p/distorm/
pip install distorm3
Options
-o OFFSET, --offset=OFFSET
EPROCESS offset (in hex) in the physical address space
-p PID, --pid=PID
Operate on these Process IDs (comma-separated)
-u, --unsafe
Bypasses certain sanity checks when creating image
-N, --no-whitelist
No whitelist (show all hooks, can be verbose)
-R, --skip-kernel
Skip kernel mode checks
-P, --skip-process
Skip process checks
-Q, --quick
Work faster by only analyzing critical processes and dlls
Output example
$ python vol.py -f /data/tmp/memory.056f443f.img --profile=Win2003SP2x86 apihooks -p 1080
Volatile Systems Volatility Framework 2.2
************************************************************************
Hook mode: Usermode
Hook type: Inline/Trampoline
Process: 1080 (svchost.exe)
Victim module: ntdll.dll (0x7c800000 - 0x7c8c3000)
Function: ntdll.dll!<unknown> at 0x7c826c4d
Hook address: 0x4fb0000
Hooking module: <unknown>

Disassembly(0):
0x7c826c4d e9ae937888       JMP 0x4fb0000
0x7c826c52 ba0003fe7f       MOV EDX, 0x7ffe0300
0x7c826c57 ff12             CALL DWORD [EDX]
0x7c826c59 c22c00           RET 0x2c
0x7c826c5c 90               NOP
0x7c826c5d b828000000       MOV EAX, 0x28
0x7c826c62 ba               DB 0xba
0x7c826c63 0003             ADD [EBX], AL

Disassembly(1):
0x4fb0000 6825b8e9c4       PUSH DWORD 0xc4e9b825
0x4fb0005 e8d37b8777       CALL 0x7c827bdd
0x4fb000a 58               POP EAX
0x4fb000b c22c00           RET 0x2c
0x4fb000e c3               RET
0x4fb000f 0f               DB 0xf
0x4fb0010 00b827000000     ADD [EAX+0x27], BH
0x4fb0016 e9               DB 0xe9
0x4fb0017 37               AAA

atoms

Description
Print session and window station atom tables
Output example
$ python vol.py -f ~/tmp/infected.img atoms
Volatile Systems Volatility Framework 2.2
 Offset(P)  Session     WindowStation          Atom  RefCount    HIndex     Pinned   Name
---------- ---------- ------------------ ---------- ---------- ---------- ---------- ----
 0xcc06c18     0       Service-0x0-3e5$      0xc00c     1          12         1      Protocols
 0xcc06c18     0       Service-0x0-3e5$      0xc00d     1          13         1      Topics
 0xcc06c18     0       Service-0x0-3e5$      0xc00e     1          14         1      Formats
 0xcc06c18     0       Service-0x0-3e5$      0xc007     1          7          1      StdShowItem
 0xcc06c18     0       Service-0x0-3e5$      0xc011     1          17         1      True
 0xcc06c18     0       Service-0x0-3e5$      0xc010     1          16         1      EditEnvItems
 0xcc06c18     0       Service-0x0-3e5$      0xc012     1          18         1      False
 0xcc06c18     0       Service-0x0-3e5$      0xc015     1          21         1      Close
 0xcc06c18     0       Service-0x0-3e5$      0xc004     1          4          1      StdEditDocument
 0xcc06c18     0       Service-0x0-3e5$      0xc008     1          8          1      StdDoVerbItem
 0xcc06c18     0       Service-0x0-3e5$      0xc003     1          3          1      StdOpenDocument
 0xcc06c18     0       Service-0x0-3e5$      0xc005     1          5          1      StdNewfromTemplate
 0xcc06c18     0       Service-0x0-3e5$      0xc014     1          20         1      Save
[REMOVED]

atomscan

Description
Pool scanner for _RTL_ATOM_TABLE
Options
-S offset, --sort-by=offset
Sort by [offset | atom | refcount]
Output example
$ python vol.py -f ~/tmp/infected.img atomscan
Volatile Systems Volatility Framework 2.2
TableOfs(P) AtomOfs(V)       Atom Refs   Pinned Name
----------- ---------- ---------- ------ ------ ----
  0x31c4da8 0xe1000d48     0xc007      1      1 FileNameW
  0x31c4da8 0xe1009148     0xc004      1      1 Native
  0x31c4da8 0xe1013340     0xc146      2      0 wuauclt_icon
  0x31c4da8 0xe101b2e0     0xc106      1      0 AFX_WM_ON_BEFORE_SHOW_RIBBON_ITEM_MENU
  0x31c4da8 0xe1022810     0xc037      1      1 SysShadow
  0x31c4da8 0xe108c620     0xc0a6      4      0 C:\WINDOWS\system32\NETSHELL.dll
  0x31c4da8 0xe10e7488     0xc159      2      0 MdmDevChg
  0x31c4da8 0xe1106478     0xc148      1      0 C:\WINDOWS\system32\wucltui.dll
  0x31c4da8 0xe1116e10     0xc157      1      0 MS Forms Text
  0x31c4da8 0xe1116e40     0xc098      2      0 MS_WebcheckMonitor
  0x31c4da8 0xe1121270     0xc13e      2      0 Progman
  0x31c4da8 0xe112fe20     0xc156      2      0 Rich Text Format Without Objects
  0x31c4da8 0xe134fbd8     0xc01e      1      1 ComboLBox
  0x31c4da8 0xe13575e8     0xc020      1      1 DDEMLMom
[REMOVED]

bioskbd

Description
Reads the keyboard buffer from Real Mode memory
Output example
$ python vol.py -f ~/tmp/infected.img bioskbd
Volatile Systems Volatility Framework 2.1
Ascii     Scancode

callbacks

Description
Print system-wide notification routines
Output example
$ python vol.py -f ~/tmp/infected.img callbacks
Volatile Systems Volatility Framework 2.1
Type                                 Callback   Module               Details
------------------------------------ ---------- -------------------- -------
IoRegisterFsRegistrationChange       0xf84d5876 sr.sys               -
IoRegisterFsRegistrationChange       0xf84d5876 sr.sys               -
IoRegisterFsRegistrationChange       0xf84d5876 sr.sys               -
IoRegisterFsRegistrationChange       0xf84d5876 sr.sys               -
KeBugCheckCallbackListHead           0xf83fd5ef NDIS.sys             Ndis miniport
KeBugCheckCallbackListHead           0xf83fd5ef NDIS.sys             Ndis miniport
KeBugCheckCallbackListHead           0x806d87cc hal.dll              ACPI 1.0 - APIC platform UP
IoRegisterShutdownNotification       0xf8bba5be Fs_Rec.SYS           \FileSystem\Fs_Rec
IoRegisterShutdownNotification       0xb250c15e vmhgfs.sys           \FileSystem\vmhgfs
IoRegisterShutdownNotification       0xf831fc6a VIDEOPRT.SYS         \Driver\VgaSave
IoRegisterShutdownNotification       0xf8bba5be Fs_Rec.SYS           \FileSystem\Fs_Rec
IoRegisterShutdownNotification       0xf831fc6a VIDEOPRT.SYS         \Driver\vmx_svga
IoRegisterShutdownNotification       0xf853b2be ftdisk.sys           \Driver\Ftdisk
IoRegisterShutdownNotification       0xf8bba5be Fs_Rec.SYS           \FileSystem\Fs_Rec
IoRegisterShutdownNotification       0xf8bba5be Fs_Rec.SYS           \FileSystem\Fs_Rec
IoRegisterShutdownNotification       0xf879dc74 Cdfs.SYS             \FileSystem\Cdfs
IoRegisterShutdownNotification       0xf831fc6a VIDEOPRT.SYS         \Driver\mnmdd
[REMOVED]

clipboard

Description
Extract the contents of the windows clipboard
Output example
$ python vol.py -f ~/memdump/stuxnet.vmem clipboard
Volatile Systems Volatility Framework 2.2
Session    WindowStation Format                 Handle Object     Data
---------- ------------- ------------------ ---------- ---------- --------------------------------------------------
         0 WinSta0       CF_UNICODETEXT      0x136012b 0xe29b0c68 74ddc49a7c121a61b8d06c03f92d0c13.exe
         0 WinSta0       CF_LOCALE            0x270101 0xe1bdab58
         0 WinSta0       CF_TEXT                   0x1 ----------
         0 WinSta0       CF_OEMTEXT                0x1 ----------

cmdscan

Description
Extract command history by scanning for _COMMAND_HISTORY
Options
-M 50, --max_history=50
CommandCountMax (default = 50)
Output example
$ python vol.py -f ~/tmp/infected.img cmdscan
Volatile Systems Volatility Framework 2.1
**************************************************
CommandProcess: csrss.exe Pid: 772
CommandHistory: 0x10c87f0 Application: mdd_1.3.exe Flags: Allocated
CommandCount: 0 LastAdded: -1 LastDisplayed: -1
FirstCommand: 0 CommandCountMax: 50
ProcessHandle: 0x3fc
**************************************************
CommandProcess: csrss.exe Pid: 772
CommandHistory: 0x10c8e50 Application: TPAutoConnect.exe Flags: Allocated
CommandCount: 0 LastAdded: -1 LastDisplayed: -1
FirstCommand: 0 CommandCountMax: 50
ProcessHandle: 0x714
**************************************************
CommandProcess: csrss.exe Pid: 772
CommandHistory: 0x10fc700 Application: cmd.exe Flags: Allocated, Reset
CommandCount: 13 LastAdded: 12 LastDisplayed: 12
FirstCommand: 0 CommandCountMax: 50
ProcessHandle: 0x434
Cmd #0 @ 0x4f1f90: dir
Cmd #1 @ 0x4f2ef8: cd .idlerc
Cmd #2 @ 0x4f2f30: dir
Cmd #3 @ 0x4f1f78: more
Cmd #4 @ 0x1108b98: more breakpoints.lst
Cmd #5 @ 0x4f2f40: more recent-files.lst
Cmd #6 @ 0x1108cc8: cd ..
Cmd #7 @ 0x10d4b40: dir
Cmd #8 @ 0x10d4888: cd "Mes documents"
Cmd #9 @ 0x10c8c40: dir
Cmd #10 @ 0x4f1eb8: cd Downloads
Cmd #11 @ 0x4f2360: dir
Cmd #12 @ 0x10d4948: mdd_1.3.exe -q -o image.img

connections

Description
Print list of open connections [Windows XP and 2003 Only] at the time the memory dump was taken.
This module follows the handle table in tcpip.sys and prints current connections.
Note that if you are using a hibernated image this might not work because Windows closes all connections before hibernating. You might find it more effective to do connscan instead.
Options
-P, --physical-offset
Physical Offset
Output example
$ python vol.py -f ~/tmp/infected.img connections
Volatile Systems Volatility Framework 2.1
Offset(V)  Local Address             Remote Address               Pid
---------- ------------------------- ------------------------- ------
0x81c6b008 192.168.1.27:1226         91.195.240.107:80            532
0x81c21008 192.168.1.27:1254         62.212.130.115:80            600
0x81c84008 192.168.1.27:1235         204.13.162.116:80            532
0x822ffc08 192.168.1.27:1224         195.216.243.2:80             532
0x81cdabc8 192.168.1.27:1255         62.212.130.115:80            600
0x81c20ba0 192.168.1.27:1298         67.215.65.132:31960         2944
0x81c71700 192.168.1.27:1237         46.45.171.124:80             532
0x81c1c910 192.168.1.27:1256         62.212.130.115:80            600
0x81e73008 192.168.1.27:1257         62.212.130.115:80            600
0x81cd0a50 192.168.1.27:1261         213.175.193.143:80           600
0x81cd9008 192.168.1.27:1236         87.248.203.254:80            532

connscan

Description
Scan Physical memory for _TCPT_OBJECT objects (tcp connections)
Output example
$ python vol.py -f ~/tmp/infected.img connscan
Volatile Systems Volatility Framework 2.1
Offset(P)  Local Address             Remote Address            Pid
---------- ------------------------- ------------------------- ---
0x01e14338 192.168.1.27:1170         74.125.230.198:80         2760
0x01e17c60 192.168.1.27:1178         173.194.70.157:80         2760
0x01e18348 192.168.1.27:1150         95.101.227.172:80         2760
0x01e18738 192.168.1.27:1141         95.101.239.144:443        2760
0x01e18a48 192.168.1.27:1127         216.34.181.69:80          2760
0x01e1ba48 192.168.1.27:1192         173.194.70.157:443        2760
0x01e1c910 192.168.1.27:1256         62.212.130.115:80         600
0x01e20ba0 192.168.1.27:1298         67.215.65.132:31960       2944
0x01e21008 192.168.1.27:1254         62.212.130.115:80         600
0x01e28930 40.120.205.129:0          78.68.97.109:0            2944
0x01e6aa98 192.168.1.27:1146         173.194.44.41:80          2760
0x01e6b008 192.168.1.27:1226         91.195.240.107:80         532
0x01e6c708 192.168.1.27:1125         95.101.227.172:80         2760
0x01e6d280 72.163.24.130:61569       0.0.0.0:49296             2177290912
0x01e71700 192.168.1.27:1237         46.45.171.124:80          532
0x01e71a10 192.168.1.27:1177         95.101.239.144:80         2760
0x01e81330 192.168.1.27:1098         74.125.230.231:443        314769412
[REMOVED]

consoles

Description
Extract command history by scanning for _CONSOLE_INFORMATION
Options
-M 50, --max_history=50
CommandCountMax (default = 50)
-B 4, --history_buffers=4
HistoryBufferMax (default = 4)
Output example
$ python vol.py consoles -f ~/tmp/infected.img
Volatile Systems Volatility Framework 2.1
**************************************************
ConsoleProcess: csrss.exe Pid: 772
Console: 0x10c8958 CommandHistorySize: 50
HistoryBufferCount: 1 HistoryBufferMax: 4
OriginalTitle: C:\Program Files\VMware\VMware Tools\TPAutoConnSvc.exe
Title: C:\Program Files\VMware\VMware Tools\TPAutoConnSvc.exe
AttachedProcess: TPAutoConnect.e Pid: 2420 Handle: 0x714
----
CommandHistory: 0x10c8e50 Application: TPAutoConnect.exe Flags: Allocated
CommandCount: 0 LastAdded: -1 LastDisplayed: -1
FirstCommand: 0 CommandCountMax: 50
ProcessHandle: 0x714
----
Screen 0x10c8c50 X:80 Y:25
Dump:
ThinPrint AutoConnect component, Copyright (c) 1999-2012 Cortado AG, 8.8.734.1
**************************************************
ConsoleProcess: csrss.exe Pid: 772
Console: 0x10d4008 CommandHistorySize: 50
HistoryBufferCount: 1 HistoryBufferMax: 4
OriginalTitle: ?O?O?m??O?O\system32\CMD.exe
Title:
**************************************************
ConsoleProcess: csrss.exe Pid: 772
Console: 0x10f04c0 CommandHistorySize: 50
HistoryBufferCount: 3 HistoryBufferMax: 4
OriginalTitle: %SystemRoot%\system32\cmd.exe
Title: C:\WINDOWS\system32\cmd.exe - mdd_1.3.exe -q -o image.img
AttachedProcess: mdd_1.3.exe Pid: 2908 Handle: 0x3fc
AttachedProcess: cmd.exe Pid: 2164 Handle: 0x434
----
CommandHistory: 0x10c87f0 Application: mdd_1.3.exe Flags: Allocated
CommandCount: 0 LastAdded: -1 LastDisplayed: -1
FirstCommand: 0 CommandCountMax: 50
ProcessHandle: 0x3fc
----
CommandHistory: 0x10c86f8 Application: more.com Flags:
CommandCount: 0 LastAdded: -1 LastDisplayed: -1
FirstCommand: 0 CommandCountMax: 50
ProcessHandle: 0x0
----
CommandHistory: 0x10fc700 Application: cmd.exe Flags: Allocated, Reset
CommandCount: 13 LastAdded: 12 LastDisplayed: 12
FirstCommand: 0 CommandCountMax: 50
ProcessHandle: 0x434
Cmd #0 at 0x4f1f90: dir
Cmd #1 at 0x4f2ef8: cd .idlerc
Cmd #2 at 0x4f2f30: dir
Cmd #3 at 0x4f1f78: more
Cmd #4 at 0x1108b98: more breakpoints.lst
Cmd #5 at 0x4f2f40: more recent-files.lst
Cmd #6 at 0x1108cc8: cd ..
Cmd #7 at 0x10d4b40: dir
Cmd #8 at 0x10d4888: cd "Mes documents"
Cmd #9 at 0x10c8c40: dir
Cmd #10 at 0x4f1eb8: cd Downloads
Cmd #11 at 0x4f2360: dir
Cmd #12 at 0x10d4948: mdd_1.3.exe -q -o image.img
----
Screen 0x10d4988 X:80 Y:300
Dump:
Microsoft Windows XP [version 5.1.2600]
(C) Copyright 1985-2001 Microsoft Corp.

C:\Documents and Settings\pilou>dir
 Le volume dans le lecteur C n'a pas de nom.
 Le num?ro de s?rie du volume est E0F1-D8A1

 R?pertoire de C:\Documents and Settings\pilou

15/09/2012  21:57    <REP>          .
15/09/2012  21:57    <REP>          ..
15/09/2012  21:57    <REP>          .idlerc
24/12/2012  13:03    <REP>          Bureau
18/03/2012  08:44    <REP>          Favoris
08/12/2011  21:44    <REP>          Menu D?marrer
03/06/2012  09:35    <REP>          Mes documents
               0 fichier(s)                0 octets
               7 R?p(s)   3?217?035?264 octets libres
[REMOVED]

crashinfo

Description
Dump crash-dump information
Output example
$ python vol.py -f win7_x64.dmp --profile=Win7SP0x64 crashinfo
Volatile Systems Volatility Framework 2.1_alpha
_DMP_HEADER64:
 Majorversion:         0x0000000f (15)
 Minorversion:         0x00001db0 (7600)
 KdSecondaryVersion    0x00000000
 DirectoryTableBase    0x32a44000
 PfnDataBase           0xfffff80002aa8220
 PsLoadedModuleList    0xfffff80002a3de50
 PsActiveProcessHead   0xfffff80002a1fb30
 MachineImageType      0x00008664
 NumberProcessors      0x00000002
 BugCheckCode          0x00000000
 KdDebuggerDataBlock   0xfffff800029e9070
 ProductType           0x00000001
 SuiteMask             0x00000110
 WriterStatus          0x00000000
 Comment               PAGEPAGEPAGEPAGEPAGEPAGE[snip]

Physical Memory Description:
Number of runs: 3
FileOffset    Start Address    Length
00002000      00001000         0009e000
000a0000      00100000         3fde0000
3fe80000      3ff00000         00100000
3ff7f000      3ffff000

deskscan

Description
Poolscaner for tagDESKTOP (desktops)
Output example
$ python vol.py -f ~/memdump/infected.img deskscan
Volatile Systems Volatility Framework 2.2
**************************************************
Desktop: 0x23c6288, Name: Service-0x0-3e5$\Default, Next: 0x0
SessionId: 0, DesktopInfo: 0xbc230650, fsHooks: 0
spwnd: 0xbc2306e8, Windows: 17
Heap: 0xbc230000, Size: 0x80000, Base: 0xbc230000, Limit: 0xbc2b0000
 1556 (svchost.exe 1504 parent 840)
 1444 (svchost.exe 1428 parent 840)
 1432 (svchost.exe 1428 parent 840)
 1336 (svchost.exe 1332 parent 840)
 1508 (svchost.exe 1504 parent 840)
**************************************************
Desktop: 0x23fb330, Name: SAWinSta\SADesktop, Next: 0x0
SessionId: 0, DesktopInfo: 0xbc640650, fsHooks: 0
spwnd: 0xbc6406e8, Windows: 20
Heap: 0xbc640000, Size: 0x80000, Base: 0xbc640000, Limit: 0xbc6c0000
**************************************************
Desktop: 0x20b48b0, Name: WinSta0\Default, Next: 0x81dc6168
SessionId: 0, DesktopInfo: 0xbbe30650, fsHooks: 0
spwnd: 0xbbe306e8, Windows: 145
Heap: 0xbbe30000, Size: 0x300000, Base: 0xbbe30000, Limit: 0xbc130000
 492 (mdd_1.3.exe 2908 parent 2164)
 2336 (explorer.exe 600 parent 796)
 2612 (explorer.exe 600 parent 796)
 2680 (vmtoolsd.exe 532 parent 272)
 2156 (cmd.exe 2164 parent 600)
[REMOVED]

devicetree

Description
Show device tree
Output example
$ python vol.py -f ~/tmp/infected.img devicetree
Volatile Systems Volatility Framework 2.1
DRV 0x01f13720 \Driver\IpFilterDriver
---| DEV 0x82295030 IPFILTERDRIVER FILE_DEVICE_NETWORK
DRV 0x01fbcb10 \Driver\swenum
---| DEV 0x81f74138 KSENUM#0000000b FILE_DEVICE_UNKNOWN
------| ATT 0x81cb8f10 KSENUM#0000000b - \Driver\kmixer FILE_DEVICE_KS
---| DEV 0x821de258 KSENUM#00000002 FILE_DEVICE_UNKNOWN
------| ATT 0x821d98d0 KSENUM#00000002 - \Driver\sysaudio FILE_DEVICE_KS
---| DEV 0x821dd590 KSENUM#00000001 FILE_DEVICE_UNKNOWN
------| ATT 0x8232d7e0 KSENUM#00000001 - \Driver\wdmaud FILE_DEVICE_KS
---| DEV 0x81dbc6c0  FILE_DEVICE_BUS_EXTENDER
DRV 0x01fbfda0 \Driver\mssmbios
---| DEV 0x82197020  FILE_DEVICE_UNKNOWN
DRV 0x01fc33b8 \FileSystem\vmhgfs
---| DEV 0x81e6d348 hgfsInternal UNKNOWN
---| DEV 0x81e65600 hgfs FILE_DEVICE_NETWORK_FILE_SYSTEM
DRV 0x01fc8f38 \FileSystem\MRxSmb
---| DEV 0x821bed80 LanmanDatagramReceiver FILE_DEVICE_NETWORK_BROWSER
---| DEV 0x81e55c00 LanmanRedirector FILE_DEVICE_NETWORK_FILE_SYSTEM
DRV 0x01fda648 \Driver\Beep
[REMOVED]

dlldump

Description
Dump DLLs from a process address space
Options
-p PID, --pid=PID
Operate on these Process IDs (comma-separated)
-D DUMP_DIR, --dump-dir=DUMP_DIR
Directory in which to dump executable files
-u, --unsafe
Bypasses certain sanity checks when creating image
-r REGEX, --regex=REGEX
Dump dlls matching REGEX
-i, --ignore-case
Ignore case in pattern match
-o OFFSET, --offset=OFFSET
Dump DLLs for Process with physical address OFFSET
-b BASE, --base=BASE
Dump DLLS at the specified BASE offset in the process address space
Output example
$ python vol.py -f ~/tmp/infected.img dlldump -p 532 --dump-dir=output/
Volatile Systems Volatility Framework 2.1
Process(V) Name                 Module Base Module Name          Result
---------- -------------------- ----------- -------------------- ------
0x81f015d0 vmtoolsd.exe         0x000400000 vmtoolsd.exe         OK: module.532.21015d0.400000.dll
0x81f015d0 vmtoolsd.exe         0x07c910000 ntdll.dll            OK: module.532.21015d0.7c910000.dll
0x81f015d0 vmtoolsd.exe         0x040d30000 ieframe.dll          Error: DllBase is paged
0x81f015d0 vmtoolsd.exe         0x000f70000 dndcp.dll            Error: DllBase is paged
0x81f015d0 vmtoolsd.exe         0x010000000 intl.dll             Error: DllBase is paged
0x81f015d0 vmtoolsd.exe         0x0719d0000 wshtcpip.dll         OK: module.532.21015d0.719d0000.dll
0x81f015d0 vmtoolsd.exe         0x07e210000 shdocvw.dll          Error: DllBase is paged
0x81f015d0 vmtoolsd.exe         0x076f80000 CLBCATQ.DLL          Error: DllBase is paged
0x81f015d0 vmtoolsd.exe         0x076e30000 rtutils.dll          OK: module.532.21015d0.76e30000.dll
[REMOVED}

dlllist

Description
Print list of loaded dlls for each process
Options
-o OFFSET, --offset=OFFSET
EPROCESS offset (in hex) in the physical address space
-p PID, --pid=PID
Operate on these Process IDs (comma-separated)
Output example
$ python vol.py -f ~/tmp/infected.img dlllist -p 532
Volatile Systems Volatility Framework 2.1
************************************************************************
vmtoolsd.exe pid:    532
Command line : "C:\Program Files\VMware\VMware Tools\vmtoolsd.exe" -n vmusr
Service Pack 3

Base             Size Path
---------- ---------- ----
0x00400000    0x11000 C:\Program Files\VMware\VMware Tools\vmtoolsd.exe
0x7c910000    0xb9000 C:\WINDOWS\system32\ntdll.dll
0x7c800000   0x106000 C:\WINDOWS\system32\kernel32.dll
0x77da0000    0xac000 C:\WINDOWS\system32\ADVAPI32.dll
0x77e50000    0x93000 C:\WINDOWS\system32\RPCRT4.dll
0x77fc0000    0x11000 C:\WINDOWS\system32\Secur32.dll
0x774a0000   0x13e000 C:\WINDOWS\system32\ole32.dll
0x77ef0000    0x49000 C:\WINDOWS\system32\GDI32.dll
0x7e390000    0x91000 C:\WINDOWS\system32\USER32.dll
0x77be0000    0x58000 C:\WINDOWS\system32\msvcrt.dll
0x77bd0000     0x8000 C:\WINDOWS\system32\VERSION.dll
0x78520000    0xa3000 C:\WINDOWS\WinSxS\x86_Microsoft.VC90.CRT_1fc8b3b9a1e18e3b_9.0.30729.4148_x-ww_d495ac4e\MSVCR90.dll
[REMOVED]

driverirp

Description
Driver IRP hook detection
Options
-r REGEX, --regex=REGEX
Analyze drivers matching REGEX
Output example
$ python vol.py -f ~/tmp/infected.img driverirp
Volatile Systems Volatility Framework 2.1
--------------------------------------------------
DriverName: IpFilterDriver
DriverStart: 0xb1a2b000
DriverSize: 0x8080
DriverStartIo: 0x0
   0 IRP_MJ_CREATE                        0xb1a2c2b4 ipfltdrv.sys
   1 IRP_MJ_CREATE_NAMED_PIPE             0xb1a2c2b4 ipfltdrv.sys
   2 IRP_MJ_CLOSE                         0xb1a2c2b4 ipfltdrv.sys
   3 IRP_MJ_READ                          0xb1a2c2b4 ipfltdrv.sys
   4 IRP_MJ_WRITE                         0xb1a2c2b4 ipfltdrv.sys
   5 IRP_MJ_QUERY_INFORMATION             0xb1a2c2b4 ipfltdrv.sys
   6 IRP_MJ_SET_INFORMATION               0xb1a2c2b4 ipfltdrv.sys
   7 IRP_MJ_QUERY_EA                      0xb1a2c2b4 ipfltdrv.sys
   8 IRP_MJ_SET_EA                        0xb1a2c2b4 ipfltdrv.sys
   9 IRP_MJ_FLUSH_BUFFERS                 0xb1a2c2b4 ipfltdrv.sys
  10 IRP_MJ_QUERY_VOLUME_INFORMATION      0xb1a2c2b4 ipfltdrv.sys
  11 IRP_MJ_SET_VOLUME_INFORMATION        0xb1a2c2b4 ipfltdrv.sys
  12 IRP_MJ_DIRECTORY_CONTROL             0xb1a2c2b4 ipfltdrv.sys
[REMOVED]

driverscan

Description
Scan for driver objects _DRIVER_OBJECT
Output example
$ python vol.py -f ~/tmp/infected.img driverscan
Volatile Systems Volatility Framework 2.1
Offset(P)  #Ptr #Hnd Start            Size Service Key          Name         Driver Name
---------- ---- ---- ---------- ---------- -------------------- ------------ -----------
0x01f13720    3    0 0xb1a2b000     0x8080 IpFilterDriver       IpFil...iver \Driver\IpFilterDriver
0x01fbcb10    9    0 0xf8bb4000     0x1100 swenum               swenum       \Driver\swenum
0x01fbfda0    3    0 0xf83a6000     0x3c80 mssmbios             mssmbios     \Driver\mssmbios
0x01fc33b8    4    0 0xb2507000    0x22800 vmhgfs               vmhgfs       \FileSystem\vmhgfs
0x01fc8f38    4    0 0xb2444000    0x6f680 MRxSmb               MRxSmb       \FileSystem\MRxSmb
0x01fda648    3    0 0xf8bbc000     0x1080 Beep                 Beep         \Driver\Beep
0x01fdaa70    3    0 0xf8a02000     0x5200 VgaSave              VgaSave      \Driver\VgaSave
0x01fdb2c0    3    0 0xf8a0a000     0x4a80 Msfs                 Msfs         \FileSystem\Msfs
0x01fdd6e8    7    0 0xb2574000    0x58480 Tcpip                Tcpip        \Driver\Tcpip
0x01fddb10    6    0 0xb254c000    0x27c00 NetBT                NetBT        \Driver\NetBT
0x01fddf38    3    0 0xf8b5a000     0x2f00 WS2IFSL              WS2IFSL      \Driver\WS2IFSL

envars

Description
Display process environment variables
Options
-o OFFSET, --offset=OFFSET
EPROCESS offset (in hex) in the physical address space
-p PID, --pid=PID
Operate on these Process IDs (comma-separated)
Output example
$ python vol.py -f ~/tmp/infected.img envars -p 532
Volatile Systems Volatility Framework 2.1
Pid      Process              Block      Variable                       Value
-------- -------------------- ---------- ------------------------------ -----
     532 vmtoolsd.exe         0x00010000 ALLUSERSPROFILE                C:\Documents and Settings\All Users
     532 vmtoolsd.exe         0x00010000 APPDATA                        C:\Documents and Settings\pilou\Application Data
     532 vmtoolsd.exe         0x00010000 CLIENTNAME                     Console
     532 vmtoolsd.exe         0x00010000 CommonProgramFiles             C:\Program Files\Fichiers communs
     532 vmtoolsd.exe         0x00010000 COMPUTERNAME                   OZ-C06A6A6F2D3C
     532 vmtoolsd.exe         0x00010000 ComSpec                        C:\WINDOWS\system32\cmd.exe
     532 vmtoolsd.exe         0x00010000 FP_NO_HOST_CHECK               NO
     532 vmtoolsd.exe         0x00010000 HOMEDRIVE                      C:
     532 vmtoolsd.exe         0x00010000 HOMEPATH                       \Documents and Settings\pilou
     532 vmtoolsd.exe         0x00010000 LOGONSERVER                    \\OZ-C06A6A6F2D3C
     532 vmtoolsd.exe         0x00010000 NUMBER_OF_PROCESSORS           1
     532 vmtoolsd.exe         0x00010000 OS                             Windows_NT
     532 vmtoolsd.exe         0x00010000 Path                           C:\WINDOWS\system32;C:\WINDOWS;C:\WINDOWS\System32\Wbem;c:\pstools;c:\python27;C:\Program Files\Nmap
[REMOVED]

eventhooks

Description
Print details on windows event hooks
Output example
$ python vol.py -f  win7x64.dd --profile=Win7SP1x64 eventhooks
Volatile Systems Volatility Framework 2.1_alpha

Handle: 0x300cb, Object: 0xfffff900c01eda10, Session: 1
Type: TYPE_WINEVENTHOOK, Flags: 0, Thread: 1516, Process: 880
eventMin: 0x4 EVENT_SYSTEM_MENUSTART
eventMax: 0x7 EVENT_SYSTEM_MENUPOPUPEND
Flags: none, offPfn: 0xff567cc4, idProcess: 0, idThread: 0
ihmod: -1

evtlogs

Description
Extract Windows Event Logs (XP/2003 only)
Options
-S, --save-evt
Save the raw .evt files also
-D DUMP_DIR, --dump-dir=DUMP_DIR
Directory in which to dump executable files
Output example
$ python vol.py -f ~/memdump/infected.img evtlogs --dump-dir=output/
Volatile Systems Volatility Framework 2.2
Parsed data sent to internet.txt
Parsed data sent to sysevent.txt
Parsed data sent to secevent.txt
Parsed data sent to thinprint.txt
Parsed data sent to appevent.txt
$ cat output/appevent.txt
2011-12-08 19:49:19|appevent.evt|OZ-C06A6A6F2D3C|N/A|LoadPerf|1000|Info|RSVP;QoS RSVP
2011-12-08 19:49:42|appevent.evt|OZ-C06A6A6F2D3C|N/A|LoadPerf|1000|Info|PSched;PSched
2011-12-08 19:49:43|appevent.evt|OZ-C06A6A6F2D3C|N/A|LoadPerf|1000|Info|RemoteAccess;Routage et accs distant
2011-12-08 19:50:01|appevent.evt|OZ-C06A6A6F2D3C|N/A|LoadPerf|1000|Info|TermService;Services Terminal Server
2011-12-08 19:50:02|appevent.evt|OZ-C06A6A6F2D3C|N/A|LoadPerf|1000|Info|MSDTC;MSDTC
2011-12-08 19:50:02|appevent.evt|OZ-C06A6A6F2D3C|N/A|MSDTC|4104|Info|N/A
2011-12-08 19:50:02|appevent.evt|OZ-C06A6A6F2D3C|N/A|MSDTC|2444|Info|0;0;0;0;0;0
2011-12-08 19:50:07|appevent.evt|OZ-C06A6A6F2D3C|N/A|LoadPerf|1000|Info|WmiApRpl;WmiApRpl
2011-12-08 19:50:07|appevent.evt|OZ-C06A6A6F2D3C|N/A|LoadPerf|1001|Info|WmiApRpl;WmiApRpl
2011-12-08 19:50:07|appevent.evt|OZ-C06A6A6F2D3C|N/A|LoadPerf|1000|Info|WmiApRpl;WmiApRpl
2011-12-08 19:50:11|appevent.evt|OZ-C06A6A6F2D3C|S-1-5-18 (Local System)|WinMgmt|63|Warning|HiPerfCooker_v1;Root\WMI
2011-12-08 19:50:12|appevent.evt|OZ-C06A6A6F2D3C|S-1-5-18 (Local System)|WinMgmt|63|Warning|CmdTriggerConsumer;Root\cimv2
2011-12-08 19:50:12|appevent.evt|OZ-C06A6A6F2D3C|S-1-5-18 (Local System)|WinMgmt|63|Warning|CmdTriggerConsumer;Root\cimv2
2011-12-08 19:50:12|appevent.evt|OZ-C06A6A6F2D3C|S-1-5-18 (Local System)|WinMgmt|5603|Warning|Rsop Planning Mode Provider;root\RSOP
[REMOVED]

filescan

Description
Scan Physical memory for _FILE_OBJECT pool allocations
Output example
$ python vol.py -f ~/memdump/infected.img filescan
Volatile Systems Volatility Framework 2.2
Offset(P)    #Ptr   #Hnd Access Name
---------- ------ ------ ------ ----
0x01e1d5d8      3      0 RWD--- \Device\HarddiskVolume1\$Directory
0x01e1d670      1      0 -W---- \Device\HarddiskVolume1\Documents and Settings\pilou\Local Settings\Application Data\Google\Chrome\User Data\chrome_shutdown_ms.txt
0x01e1e970      3      0 RWD--- \Device\HarddiskVolume1\$Directory
0x01e1f890      1      0 R--rwd \Device\HarddiskVolume1\WINDOWS\system32\d3d8thk.dll
0x01e26628      1      0 R--r-- \Device\HarddiskVolume1\WINDOWS\system32\win32k.sys
0x01e26a90      1      0 R--rw- \Device\HarddiskVolume1\Documents and Settings\pilou\Local Settings\Application Data\Google\Chrome\User Data\Default\Session Storage\000005.sst
0x01e27628      1      0 -WD--- \Device\HarddiskVolume1??INDOWS\SoftwareDistribution\Download\2b92e2dcf8ad4df7317e353becd67cd7\_useselfcontained_.state
0x01e28e70      1      0 RW-rw- \Device\HarddiskVolume1\Documents and Settings\pilou\Local Settings\Application Data\Google\Chrome\User Data\Default\Network Action Predictor
0x01e29bb8      1      0 -WD--- \Device\HarddiskVolume1????DOWS\SoftwareDistributio??????
0x01e29c50      1      0 -WD--- \Device\HarddiskVolume1\WINDOWS\SoftwareDistribution\Download\e07b1f39ad7efdd3145745a305217a88\_unpacked_.state
0x01e29ce8      1      0 -WD--- \Device\HarddiskVolume1????DOWS\SoftwareDistribution\Download\e07b1f39ad7efdd3145745a305217a88\_downloadprogress_.state
0x01e2a1b8      1      0 R--r-d \Device\HarddiskVolume1\WINDOWS\system32\h323.tsp
0x01e2a510      1      1 R--rw- \Device\HarddiskVolume1\WINDOWS\WinSxS\x86_Microsoft.Windows.Common-Controls_6595b64144ccf1df_6.0.2600.6028_x-ww_61e65202
0x01e2b450      3      0 RWD--- \Device\HarddiskVolume1\$Directory
[REMOVED]

gahti

Description
Dump the USER handle type information
Output example
$ python vol.py -f ~/memdump/infected.img gahti
Volatile Systems Volatility Framework 2.2
Session  Type                 Tag      fnDestroy  Flags
-------- -------------------- -------- ---------- -----
       0 TYPE_FREE                     0x00000000
       0 TYPE_WINDOW          Uswd     0xbf89dd3b OCF_DESKTOPHEAP, OCF_THREADOWNED, OCF_USEPOOLIFNODESKTOP, OCF_USEPOOLQUOTA
       0 TYPE_MENU                     0xbf896641 OCF_DESKTOPHEAP, OCF_PROCESSOWNED
       0 TYPE_CURSOR          Uscu     0xbf89ed85 OCF_MARKPROCESS, OCF_PROCESSOWNED, OCF_USEPOOLQUOTA
       0 TYPE_SETWINDOWPOS    Ussw     0xbf81f9c4 OCF_THREADOWNED, OCF_USEPOOLQUOTA
       0 TYPE_HOOK                     0xbf860442 OCF_DESKTOPHEAP, OCF_THREADOWNED
       0 TYPE_CLIPDATA        Uscb     0xbf91c359
       0 TYPE_CALLPROC                 0xbf85df2f OCF_DESKTOPHEAP, OCF_PROCESSOWNED
       0 TYPE_ACCELTABLE      Usac     0xbf85df2f OCF_PROCESSOWNED, OCF_USEPOOLQUOTA
       0 TYPE_DDEACCESS       Usd9     0xbf91c359 OCF_THREADOWNED, OCF_USEPOOLQUOTA
       0 TYPE_DDECONV         UsdA     0xbf922619 OCF_THREADOWNED, OCF_USEPOOLQUOTA
       0 TYPE_DDEXACT         UsdB     0xbf922560 OCF_THREADOWNED, OCF_USEPOOLQUOTA
       0 TYPE_MONITOR         Usdi     0xbf931dfd OCF_SHAREDHEAP
       0 TYPE_KBDLAYOUT       Uskb     0xbf912a22
       0 TYPE_KBDFILE         Uskf     0xbf92a5c9
       0 TYPE_WINEVENTHOOK    Uswe     0xbf8ebdce OCF_THREADOWNED
       0 TYPE_TIMER           Ustm     0xbf80e874
       0 TYPE_INPUTCONTEXT    Usim     0xbf92b18d OCF_DESKTOPHEAP, OCF_THREADOWNED
       0 TYPE_HIDDATA         Usha     0xbf93291a OCF_THREADOWNED
       0 TYPE_DEVICEINFO      UsDI     0xbf881c48

gditimers

Description
Print installed GDI timers and callbacks
Output example
$ python vol.py -f ~/memdump/infected.img gditimers
Volatile Systems Volatility Framework 2.2
 Sess      Handle Object     Thread   Process                     nID Rate(ms)   Countdown(ms) Func
------ ---------- ---------- -------- -------------------- ---------- ---------- ------------- ----------
  0       0x20033 0xe1956800      808 -:-                      0x7ffe       1000           171 0xbf8012fb
  0      0x130053 0xe168ebc8      808 -:-                      0x7ffd      35000         29359 0xbf8f3acc
  0       0x10087 0xe1c1b818     1812 -:-                      0x7ffb      60000         38093 0x74ec1070
  0       0x200cf 0xe20c46f0      812 -:-                      0xfff5        100           100 0xbf80a556
  0       0x400d5 0xe1e8f298      556 -:-                        0x15      60000          3031 0x00000000
  0       0x400d9 0xe1ee3008      556 -:-                        0x19   86400000      85626532 0x00000000
  0       0xc00fb 0xe17b2178      896 -:-                       0x3e8   14400000      13401860 0x00000000
  0      0x460107 0xe185e4c0      556 -:-                         0x0      60000          6625 0x00000000
  0     0x2470135 0xe18206a0      508 -:-                         0x1        530           437 0x00000000
  0      0x740147 0xe24bea88      556 -:-                         0xe   43200000      42426328 0x00000000
  0       0x60153 0xe1eda860     2572 -:-                      0x7fc9       1000           937 0x763ee0eb
  0       0x201a1 0xe1f31e40     1656 -:-                         0x0     300000        251312 0x774f2d77
  0       0xa021d 0xe21e8120      896 -:-                       0x3e9   86400000      85397375 0x00000000

gdt

Description
Display Global Descriptor Table
Output example
$ python vol.py -f ~/memdump/infected.img gdt
Volatile Systems Volatility Framework 2.2
   CPU        Sel Base       Limit      Type              DPL Gr   Pr
------ ---------- ---------- ---------- -------------- ------ ---- ----
     0        0x0 0x00000000 0x00000000 <Reserved>          0 By   Np
     0        0x8 0x00000000 0xffffffff Code RE Ac          0 Pg   P
     0       0x10 0x00000000 0xffffffff Data RW Ac          0 Pg   P
     0       0x18 0x00000000 0xffffffff Code RE Ac          3 Pg   P
     0       0x20 0x00000000 0xffffffff Data RW Ac          3 Pg   P
     0       0x28 0x80042000 0x000020ab TSS32 Busy          0 By   P
     0       0x30 0xffdff000 0x00001fff Data RW Ac          0 Pg   P
     0       0x38 0x7ffdd000 0x00000fff Data RW Ac          3 By   P
     0       0x40 0x00000400 0x0000ffff Data RW             3 By   P
     0       0x48 0x00000000 0x00000000 <Reserved>          0 By   Np
     0       0x50 0x8054a080 0x00000068 TSS32 Avl           0 By   P
     0       0x58 0x8054a0e8 0x00000068 TSS32 Avl           0 By   P
     0       0x60 0x00022f40 0x0000ffff Data RW Ac          0 By   P
     0       0x68 0x000b8000 0x00003fff Data RW             0 By   P
     0       0x70 0xffff7000 0x000003ff Data RW             0 By   P
     0       0x78 0x80400000 0x0000ffff Code RE             0 By   P
     0       0x80 0x80400000 0x0000ffff Data RW             0 By   P
     0       0x88 0x00000000 0x00000000 Data RW             0 By   P
[REMOVED]

getservicesids

Description
Get the names of services in the Registry and return Calculated SID
Output example
$ python vol.py -f ~/memdump/infected.img getservicesids
Volatile Systems Volatility Framework 2.2
servicesids = {
    'S-1-5-80-2675092186-3691566608-1139246469-1504068187-1286574349': 'Abiosdsk',
    'S-1-5-80-384935-177232180-2275229793-1867620679-4069250810': 'abp470n5',
    'S-1-5-80-2200411935-3214395760-3985565908-2861215955-1226862917': 'abp480n5',
    'S-1-5-80-850610371-2162948594-2204246734-1395993891-583065928': 'ACPIEC',
    'S-1-5-80-3725335247-1751848567-2456254030-120447533-3735992947': 'AdobeFlashPlayerUpdateSvc',
    'S-1-5-80-2838020983-819055183-730598559-323496739-448665943': 'adpu160m',
    'S-1-5-80-3218321610-3296847771-3570773115-868698368-3117473630': 'aec',
    'S-1-5-80-934984265-4079461471-3978616717-2318450786-290302611': 'Aha154x',
    'S-1-5-80-1344778701-2960353790-662938617-678076498-4183748354': 'aic78u2',
    'S-1-5-80-1076555770-1261388817-3553637611-899283093-3303637635': 'Alerter',
    'S-1-5-80-1587539839-2488332913-1287008632-3751426284-4220573165': 'AliIde',
    'S-1-5-80-3980410673-3391719637-2113285402-1294014731-1235999994': 'amsint',
    'S-1-5-80-2636016386-2318576122-4003064359-4163118804-2687887603': 'asc',
    'S-1-5-80-3570203740-1408783918-3026009114-267332295-1428103130': 'asc3350p',
[REMOVED]

getsids

Description
Print the SIDs owning each process
Options
-o OFFSET, --offset=OFFSET
EPROCESS offset (in hex) in the physical address space
-p PID, --pid=PID
Operate on these Process IDs (comma-separated)
Output example
$ python vol.py -f ~/memdump/infected.img getsids -p 532
Volatile Systems Volatility Framework 2.2
vmtoolsd.exe (532): S-1-5-21-1801674531-1647877149-682003330-1003
vmtoolsd.exe (532): S-1-5-21-1801674531-1647877149-682003330-513 (Domain Users)
vmtoolsd.exe (532): S-1-1-0 (Everyone)
vmtoolsd.exe (532): S-1-5-32-544 (Administrators)
vmtoolsd.exe (532): S-1-5-32-545 (Users)
vmtoolsd.exe (532): S-1-5-4 (Interactive)
vmtoolsd.exe (532): S-1-5-11 (Authenticated Users)
vmtoolsd.exe (532): S-1-5-5-0-65129 (Logon Session)
vmtoolsd.exe (532): S-1-2-0 (Local (Users with the ability to log in locally))
[REMOVED]

handles

Description
Print list of open handles for each process
Options
-o OFFSET, --offset=OFFSET
EPROCESS offset (in hex) in the physical address space
-p PID, --pid=PID
Operate on these Process IDs (comma-separated)
-P, --physical-offset
Physical Offset
-t OBJECT_TYPE, --object-type=OBJECT_TYPE
Show these object types (comma-separated)
-s, --silent
Suppress less meaningful results
Output example
$ python vol.py -f ~/memdump/infected.img handles -p 532 -s
Volatile Systems Volatility Framework 2.2
Offset(V)     Pid     Handle     Access Type             Details
---------- ------ ---------- ---------- ---------------- -------
0xe1005448    532        0x4    0xf0003 KeyedEvent       CritSecOutOfMemoryEvent
0xe182a4d8    532        0x8        0x3 Directory        KnownDlls
0x8223c190    532        0xc   0x100020 File             \Device\HarddiskVolume1\Documents and Settings\pilou
0x81dd4d00    532       0x10   0x100020 File             \Device\HarddiskVolume1\WINDOWS\WinSxS\x86_Microsoft.VC90.CRT_1fc8b3b9a1e18e3b_9.0.30729.4148_x-ww_d495ac4e
0xe193c768    532       0x14    0xf000f Directory        Windows
0x81dc6028    532       0x1c   0x100020 File             \Device\HarddiskVolume1\WINDOWS\WinSxS\x86_Microsoft.VC90.CRT_1fc8b3b9a1e18e3b_9.0.30729.4148_x-ww_d495ac4e
0x81f21bb0    532       0x20   0x100020 File             \Device\HarddiskVolume1\WINDOWS\WinSxS\x86_Microsoft.VC90.CRT_1fc8b3b9a1e18e3b_9.0.30729.4148_x-ww_d495ac4e
0x81e5bdb8    532       0x28   0x100020 File             \Device\HarddiskVolume1\WINDOWS\WinSxS\x86_Microsoft.VC90.CRT_1fc8b3b9a1e18e3b_9.0.30729.4148_x-ww_d495ac4e
0x81dd07b0    532       0x2c   0x100020 File             \Device\HarddiskVolume1\WINDOWS\WinSxS\x86_Microsoft.VC90.CRT_1fc8b3b9a1e18e3b_9.0.30729.4148_x-ww_d495ac4e
0x8227c2b0    532       0x30   0x100020 File             \Device\HarddiskVolume1\WINDOWS\WinSxS\x86_Microsoft.VC90.CRT_1fc8b3b9a1e18e3b_9.0.30729.4148_x-ww_d495ac4e
0x821b5300    532       0x34   0x100020 File             \Device\HarddiskVolume1\WINDOWS\WinSxS\x86_Microsoft.VC90.CRT_1fc8b3b9a1e18e3b_9.0.30729.4148_x-ww_d495ac4e
0x81e837c0    532       0x38   0x100020 File             \Device\HarddiskVolume1\WINDOWS\WinSxS\x86_Microsoft.VC90.CRT_1fc8b3b9a1e18e3b_9.0.30729.4148_x-ww_d495ac4e
0xe1e7de28    532       0x40  0x20f003f Key              MACHINE
0x81f722d0    532       0x44    0xf037f WindowStation    WinSta0
0x81eb48b0    532       0x4c    0xf01ff Desktop          Default
0x81f722d0    532       0x50    0xf037f WindowStation    WinSta0
0x82285ea8    532       0x54   0x100001 File             \Device\KsecDD
[REMOVED]

hashdump

Description
Dumps passwords hashes (LM/NTLM) from memory
Options
-y SYS_OFFSET, --sys-offset=SYS_OFFSET
SYSTEM hive offset (virtual)
-s SAM_OFFSET, --sam-offset=SAM_OFFSET
SAM hive offset (virtual)
Output example

We need the hive list so we can get the starting location in memory where the registry information resides:

$ python vol.py -f ~/memdump/infected.img hivelist
Volatile Systems Volatility Framework 2.2
Virtual    Physical   Name
---------- ---------- ----
0xe2084008 0x0fe6b008 \Device\HarddiskVolume1\Documents and Settings\pilou\Local Settings\Application Data\Microsoft\Windows\UsrClass.dat
0xe1d1fb60 0x0db99b60 \Device\HarddiskVolume1\Documents and Settings\pilou\NTUSER.DAT
0xe19d8380 0x0d091380 \Device\HarddiskVolume1\Documents and Settings\LocalService\Local Settings\Application Data\Microsoft\Windows\UsrClass.dat
0xe1c19508 0x0d644508 \Device\HarddiskVolume1\Documents and Settings\LocalService\NTUSER.DAT
0xe17206d0 0x0cad76d0 \Device\HarddiskVolume1\Documents and Settings\NetworkService\Local Settings\Application Data\Microsoft\Windows\UsrClass.dat
0xe19fb008 0x0d403008 \Device\HarddiskVolume1\Documents and Settings\NetworkService\NTUSER.DAT
0xe196c6b8 0x0a9ca6b8 \Device\HarddiskVolume1\WINDOWS\system32\config\software
0xe1599b60 0x04870b60 \Device\HarddiskVolume1\WINDOWS\system32\config\default
0xe196cb60 0x0a9cab60 \Device\HarddiskVolume1\WINDOWS\system32\config\SECURITY
0xe195eb60 0x0a6e2b60 \Device\HarddiskVolume1\WINDOWS\system32\config\SAM
0xe134f350 0x02f00350 [no name]
0xe1035b60 0x02aa3b60 \Device\HarddiskVolume1\WINDOWS\system32\config\system
0xe102e008 0x02a9d008 [no name]
0x806717a8 0x006717a8 [no name]

Then dump the hashes as follows:

$ python vol.py -f ~/memdump/infected.img hashdump -s 0xe195eb60 -y 0xe1035b60
Volatile Systems Volatility Framework 2.2
Administrateur:500:e039e3178e07d0c9a6e1e67c15d6275b:b246b548b6f17e45f349aa2214a5f6aa:::

You can then use online resources or a has cracker like John to crack the hash.

hibinfo

Description
Dump hibernation file information
Output example
$ python vol.py -f hiberfil.sys --profile=Win7SP1x64 hibinfo
IMAGE_HIBER_HEADER:
Signature: HIBR
SystemTime: 2011-12-23 16:34:27

Control registers flags
CR0: 80050031
CR0[PAGING]: 1
CR3: 00187000
CR4: 000006f8
CR4[PSE]: 1
CR4[PAE]: 1

Windows Version is 6.1 (7601)

hivedump

Description
Prints out a hive
Options
-o HIVE_OFFSET, --hive-offset=HIVE_OFFSET
Hive offset (virtual)
Output example

See hivelist to get the offset of a hive

$ python vol.py -f ~/memdump/infected.img hivedump -o 0xe196cb60
Volatile Systems Volatility Framework 2.2
Last Written         Key
2013-02-18 20:54:33  \SECURITY
2012-03-17 16:29:11  \SECURITY\Cache
2011-12-08 19:49:19  \SECURITY\Policy
2011-12-08 20:00:07  \SECURITY\Policy\Accounts
2011-12-08 20:44:26  \SECURITY\Policy\Accounts\S-1-1-0
2011-12-08 20:44:58  \SECURITY\Policy\Accounts\S-1-1-0\ActSysAc
2011-12-08 20:44:58  \SECURITY\Policy\Accounts\S-1-1-0\Privilgs
2011-12-08 20:44:26  \SECURITY\Policy\Accounts\S-1-1-0\SecDesc
2011-12-08 20:44:26  \SECURITY\Policy\Accounts\S-1-1-0\Sid
2011-12-08 20:44:58  \SECURITY\Policy\Accounts\S-1-5-19
[REMOVED]

hivelist

Description
Print list of registry hives.
Output example
$ python vol.py -f ~/memdump/infected.img hivelist
Volatile Systems Volatility Framework 2.2
Virtual    Physical   Name
---------- ---------- ----
0xe2084008 0x0fe6b008 \Device\HarddiskVolume1\Documents and Settings\pilou\Local Settings\Application Data\Microsoft\Windows\UsrClass.dat
0xe1d1fb60 0x0db99b60 \Device\HarddiskVolume1\Documents and Settings\pilou\NTUSER.DAT
0xe19d8380 0x0d091380 \Device\HarddiskVolume1\Documents and Settings\LocalService\Local Settings\Application Data\Microsoft\Windows\UsrClass.dat
0xe1c19508 0x0d644508 \Device\HarddiskVolume1\Documents and Settings\LocalService\NTUSER.DAT
0xe17206d0 0x0cad76d0 \Device\HarddiskVolume1\Documents and Settings\NetworkService\Local Settings\Application Data\Microsoft\Windows\UsrClass.dat
0xe19fb008 0x0d403008 \Device\HarddiskVolume1\Documents and Settings\NetworkService\NTUSER.DAT
0xe196c6b8 0x0a9ca6b8 \Device\HarddiskVolume1\WINDOWS\system32\config\software
0xe1599b60 0x04870b60 \Device\HarddiskVolume1\WINDOWS\system32\config\default
0xe196cb60 0x0a9cab60 \Device\HarddiskVolume1\WINDOWS\system32\config\SECURITY
0xe195eb60 0x0a6e2b60 \Device\HarddiskVolume1\WINDOWS\system32\config\SAM
0xe134f350 0x02f00350 [no name]
0xe1035b60 0x02aa3b60 \Device\HarddiskVolume1\WINDOWS\system32\config\system
0xe102e008 0x02a9d008 [no name]
0x806717a8 0x006717a8 [no name]
[REMOVED]

Windows NT-based systems store the registry in a binary file format which can be exported, loaded and unloaded by the Registry Editor in these operating systems. The following system Registry files are stored in %SystemRoot%\System32\Config\:

  • Sam – HKEY_LOCAL_MACHINE\SAMSecurity – HKEY_LOCAL_MACHINE\SECURITY
  • Software – HKEY_LOCAL_MACHINE\SOFTWARE
  • System – HKEY_LOCAL_MACHINE\SYSTEM
  • Default – HKEY_USERS\.DEFAULT
  • Userdiff – Not associated with a hive. Used only when upgrading operating systems.[29]

The following file is stored in each user's profile folder:

  • %UserProfile%\Ntuser.dat – HKEY_USERS\<User SID> (linked to by HKEY_CURRENT_USER)

For Windows 2000, Server 2003 and Windows XP, the following additional user-specific file is used for file associations and COM information:

  • %UserProfile%\Local Settings\Application Data\Microsoft\Windows\Usrclass.dat (path is localized) – HKEY_USERS\<User SID>_Classes (HKEY_CURRENT_USER\Software\Classes)

For Windows Vista and later, the path was changed to:

  • %UserProfile%\AppData\Local\Microsoft\Windows\Usrclass.dat (path is not localized) alias %LocalAppData%\Microsoft\Windows\Usrclass.dat – HKEY_USERS\<User SID>_Classes (HKEY_CURRENT_USER\Software\Classes)

Windows 2000 kept an alternate copy of the registry hives (.ALT) and attempts to switch to it when corruption is detected.[30] Windows XP and Windows Server 2003 do not maintain a System.alt hive because NTLDR on those versions of Windows can process the System.log file to bring up to date a System hive that has become inconsistent during a shutdown or crash. In addition, the %SystemRoot%\Repair folder contains a copy of the system's registry hives that were created after installation and the first successful startup of Windows. Each registry data file has an associated file with a ".log" extension that acts as a transaction log that is used to ensure that any interrupted updates can be completed upon next startup.[31] Internally, registry files are split into 4 kB "bins" that contain collections of "cells".

For more information, please refer to http://en.wikipedia.org/wiki/Windows_Registry.

hivescan

Description
Scan Physical memory for _CMHIVE objects (registry hives)
Output example
$ python vol.py -f ~/memdump/infected.img hivescan
Volatile Systems Volatility Framework 2.2
Offset(P)
----------
0x02a9d008
0x02aa3b60
0x02f00350
0x04870b60
0x0a6e2b60
0x0a9ca6b8
0x0a9cab60
0x0c0d6350
0x0cad76d0
0x0d091380
0x0d403008
0x0d644508
0x0db99b60
0x0fe6b008
0x13037b60
0x160dc008
0x16186380
0x16745350
0x16e85b60
0x18960b60
0x1a0f8008
0x1ebf5008

idt

Description
Display Interrupt Descriptor Table
Output example
$ python vol.py -f ~/memdump/infected.img idt
Volatile Systems Volatility Framework 2.2
   CPU  Index Selector Value      Module               Section
------ ------ -------- ---------- -------------------- ------------
     0      0        8 0x8053e29c ntoskrnl.exe         .text
     0      1        8 0x8053e414 ntoskrnl.exe         .text
     0      2       88 0x00000000 ntoskrnl.exe
     0      3        8 0x8053e7e4 ntoskrnl.exe         .text
     0      4        8 0x8053e964 ntoskrnl.exe         .text
     0      5        8 0x8053eac0 ntoskrnl.exe         .text
     0      6        8 0x8053ec34 ntoskrnl.exe         .text
     0      7        8 0x8053f29c ntoskrnl.exe         .text
     0      8       80 0x00000000 ntoskrnl.exe
     0      9        8 0x8053f6c0 ntoskrnl.exe         .text
     0      A        8 0x8053f7e0 ntoskrnl.exe         .text
     0      B        8 0x8053f920 ntoskrnl.exe         .text
     0      C        8 0x8053fb7c ntoskrnl.exe         .text
     0      D        8 0x8053fe60 ntoskrnl.exe         .text
     0      E        8 0x80540568 ntoskrnl.exe         .text
     0      F        8 0x80540898 ntoskrnl.exe         .text
     0     10        8 0x805409b8 ntoskrnl.exe         .text
     0     11        8 0x80540af0 ntoskrnl.exe         .text
     0     12      160 0x80540898 UNKNOWN
     0     13        8 0x80540c58 ntoskrnl.exe         .text
     0     14        8 0x80540898 ntoskrnl.exe         .text
     0     15        8 0x80540898 ntoskrnl.exe         .text
[REMOVED}

imagecopy

Description
convert any existing type of address space (such as a crashdump, hibernation file, or live firewire session) to a raw memory image
Options
-b 5242880, --blocksize=5242880
Size (in bytes) of blocks to copy
-O OUTPUT_IMAGE, --output-image=OUTPUT_IMAGE
Writes a raw DD image out to OUTPUT-IMAGE
Output example
$ python vol.py imagecopy -f win7.dmp --profile=Win7SP0x86 -O win7.raw
Volatile Systems Volatility Framework 2.0
Writing data (5.00 MB chunks): |.....................................................|

imageinfo

Description
Identify information for the image
Output example
$ python vol.py -f ~/tmp/infected.img imageinfo
Volatile Systems Volatility Framework 2.1
Determining profile based on KDBG search...

          Suggested Profile(s) : WinXPSP2x86, WinXPSP3x86 (Instantiated with WinXPSP2x86)
                     AS Layer1 : JKIA32PagedMemoryPae (Kernel AS)
                     AS Layer2 : FileAddressSpace (/Users/sebastiendamaye/tmp/infected.img)
                      PAE type : PAE
                           DTB : 0x31e000L
                          KDBG : 0x80545c60
          Number of Processors : 1
     Image Type (Service Pack) : 3
                KPCR for CPU 0 : 0xffdff000
             KUSER_SHARED_DATA : 0xffdf0000
           Image date and time : 2013-02-18 21:20:52 UTC+0000
     Image local date and time : 2013-02-18 22:20:52 +0100

impscan

Description
Scan for calls to imported functions
Options
-p PID, --pid=PID
Process ID (leave off to scan kernel memory)
-b BASE, --base=BASE
Base address in process memory if --pid is supplied, otherwise an address in kernel space
-s SIZE, --size=SIZE
Size of memory to scan
Output example
$ python vol.py -f ~/memdump/infected.img impscan -p 532
Volatile Systems Volatility Framework 2.2
IAT        Call       Module               Function
---------- ---------- -------------------- --------
0x00407000 0x77da7cb8 ADVAPI32.dll         FreeSid
0x00407004 0x77db4b05 ADVAPI32.dll         SetSecurityDescriptorOwner
0x00407008 0x77da79eb ADVAPI32.dll         SetSecurityDescriptorDacl
0x0040700c 0x77da79c6 ADVAPI32.dll         InitializeSecurityDescriptor
0x00407010 0x77db4ec2 ADVAPI32.dll         SetEntriesInAclW
0x00407014 0x77da7cc9 ADVAPI32.dll         AllocateAndInitializeSid
0x00407054 0x7c81f424 kernel32.dll         IsDebuggerPresent
0x00407058 0x7c864042 kernel32.dll         UnhandledExceptionFilter
0x0040705c 0x7c801e1a kernel32.dll         TerminateProcess
0x00407060 0x7c8017e9 kernel32.dll         GetSystemTimeAsFileTime
0x00407064 0x7c8099c0 kernel32.dll         GetCurrentProcessId
0x00407068 0x7c8097d0 kernel32.dll         GetCurrentThreadId
[REMOVED]

kdbgscan

Description
Search for and dump potential KDBG values
Output example
$ python vol.py -f ~/memdump/infected.img kdbgscan
Volatile Systems Volatility Framework 2.2
**************************************************
Instantiating KDBG using: Kernel AS WinXPSP2x86 (5.1.0 32bit)
Offset (V)                    : 0x80545c60
Offset (P)                    : 0x545c60
KDBG owner tag check          : True
Profile suggestion (KDBGHeader): WinXPSP3x86
Version64                     : 0x80545c38 (Major: 15, Minor: 2600)
Service Pack (CmNtCSDVersion) : 3
Build string (NtBuildLab)     : 2600.xpsp_sp3_gdr.120821-1629
PsActiveProcessHead           : 0x8055a2d8 (35 processes)
PsLoadedModuleList            : 0x80554140 (124 modules)
KernelBase                    : 0x804d7000 (Matches MZ: True)
Major (OptionalHeader)        : 5
Minor (OptionalHeader)        : 1
KPCR                          : 0xffdff000 (CPU 0)
[REMOVED]

kpcrscan

Description
Search for and dump potential KPCR (Kernel Processor Control Region) values
Output example
$ python vol.py --profile=Win7SP0x86 -f win7.dmp kpcrscan
Volatile Systems Volatility Framework 2.0
Potential KPCR structure virtual addresses:
 _KPCR: 0x8296dc00

ldrmodules

Description
Detect unlinked DLLs
Options
-o OFFSET, --offset=OFFSET
EPROCESS offset (in hex) in the physical address space
-p PID, --pid=PID
Operate on these Process IDs (comma-separated)
Output example
$ python vol.py -f ~/memdump/infected.img ldrmodules -p 532
Volatile Systems Volatility Framework 2.2
Pid      Process              Base       InLoad InInit InMem MappedPath
-------- -------------------- ---------- ------ ------ ----- ----------
     532 vmtoolsd.exe         0x01ef0000 True   True   True  \WINDOWS\system32\vmhgfs.dll
     532 vmtoolsd.exe         0x00400000 True   False  True  \Program Files\VMware\VMware Tools\vmtoolsd.exe
     532 vmtoolsd.exe         0x76930000 True   True   True  \WINDOWS\system32\ntshrui.dll
     532 vmtoolsd.exe         0x77f40000 True   True   True  \WINDOWS\system32\shlwapi.dll
     532 vmtoolsd.exe         0x62e40000 True   True   True  \WINDOWS\system32\hnetcfg.dll
     532 vmtoolsd.exe         0x77be0000 True   True   True  \WINDOWS\system32\msvcrt.dll
     532 vmtoolsd.exe         0x71990000 True   True   True  \WINDOWS\system32\mswsock.dll
     532 vmtoolsd.exe         0x779e0000 True   True   True  \WINDOWS\system32\crypt32.dll
     532 vmtoolsd.exe         0x778e0000 True   True   True  \WINDOWS\system32\setupapi.dll
     532 vmtoolsd.exe         0x77fc0000 True   True   True  \WINDOWS\system32\secur32.dll
     532 vmtoolsd.exe         0x719d0000 True   True   True  \WINDOWS\system32\wshtcpip.dll
     532 vmtoolsd.exe         0x71be0000 True   True   True  \WINDOWS\system32\netrap.dll
[REMOVED]

lsadump

Description
Dump (decrypted) LSA secrets from the registry
Options
-y SYS_OFFSET, --sys-offset=SYS_OFFSET
SYSTEM hive offset (virtual)
-s SEC_OFFSET, --sec-offset=SEC_OFFSET
SECURITY hive offset (virtual)
Output example
N/A

malfind

Description
Find hidden and injected code
Options
-o OFFSET, --offset=OFFSET
EPROCESS offset (in hex) in the physical address space
-p PID, --pid=PID
Operate on these Process IDs (comma-separated)
-D DUMP_DIR, --dump-dir=DUMP_DIR
Directory in which to dump the VAD files
Output example
$ python vol.py -f ~/memdump/infected.img malfind -p 532 -D output/
Volatile Systems Volatility Framework 2.2
Process: vmtoolsd.exe Pid: 532 Address: 0x3140000
Vad Tag: VadS Protection: PAGE_EXECUTE_READWRITE
Flags: CommitCharge: 4147, MemCommit: 1, PrivateMemory: 1, Protection: 6

0x03140000  4d 5a 90 00 03 00 00 00 04 00 00 00 ff ff 00 00   MZ..............
0x03140010  b8 00 00 00 00 00 00 00 40 00 00 00 00 00 00 00   [email protected]
0x03140020  00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00   ................
0x03140030  00 00 00 00 00 00 00 00 00 00 00 00 e0 00 00 00   ................

0x3140000 4d               DEC EBP
0x3140001 5a               POP EDX
0x3140002 90               NOP
0x3140003 0003             ADD [EBX], AL
0x3140005 0000             ADD [EAX], AL
0x3140007 000400           ADD [EAX+EAX], AL
0x314000a 0000             ADD [EAX], AL
0x314000c ff               DB 0xff
0x314000d ff00             INC DWORD [EAX]
0x314000f 00b800000000     ADD [EAX+0x0], BH
0x3140015 0000             ADD [EAX], AL
0x3140017 004000           ADD [EAX+0x0], AL
0x314001a 0000             ADD [EAX], AL
0x314001c 0000             ADD [EAX], AL
0x314001e 0000             ADD [EAX], AL
0x3140020 0000             ADD [EAX], AL
0x3140022 0000             ADD [EAX], AL
0x3140024 0000             ADD [EAX], AL
0x3140026 0000             ADD [EAX], AL
0x3140028 0000             ADD [EAX], AL
0x314002a 0000             ADD [EAX], AL
0x314002c 0000             ADD [EAX], AL
0x314002e 0000             ADD [EAX], AL
0x3140030 0000             ADD [EAX], AL
0x3140032 0000             ADD [EAX], AL
0x3140034 0000             ADD [EAX], AL
0x3140036 0000             ADD [EAX], AL
0x3140038 0000             ADD [EAX], AL
0x314003a 0000             ADD [EAX], AL
0x314003c e000             LOOPNZ 0x314003e
0x314003e 0000             ADD [EAX], AL
[REMOVED]

memdump

Description
Dump the addressable memory for a process
Options
-o OFFSET, --offset=OFFSET
EPROCESS offset (in hex) in the physical address space
-p PID, --pid=PID
Operate on these Process IDs (comma-separated)
-D DUMP_DIR, --dump-dir=DUMP_DIR
Directory in which to dump memory
Output example
$ python vol.py -f ~/memdump/infected.img memdump -p 532 --dump-dir output/
Volatile Systems Volatility Framework 2.2
************************************************************************
Writing vmtoolsd.exe [   532] to 532.dmp

memmap

Description
Print the memory map
Options
-o OFFSET, --offset=OFFSET
EPROCESS offset (in hex) in the physical address space
-p PID, --pid=PID
Operate on these Process IDs (comma-separated)
Output example
$ python vol.py -f ~/memdump/infected.img memmap -p 532
Volatile Systems Volatility Framework 2.2
vmtoolsd.exe pid:    532
Virtual    Physical         Size DumpFileOffset
---------- ---------- ---------- --------------
0x00010000 0x11bb9000     0x1000            0x0
0x00020000 0x11b7a000     0x1000         0x1000
0x00126000 0x11f02000     0x1000         0x2000
0x00127000 0x12041000     0x1000         0x3000
0x00128000 0x12340000     0x1000         0x4000
0x00129000 0x11f3f000     0x1000         0x5000
0x0012a000 0x11ffe000     0x1000         0x6000
0x0012b000 0x1203d000     0x1000         0x7000
[REMOVED]

messagehooks

Description
List desktop and thread window message hooks
Options
Output example
$ python vol.py -f laqma.vmem messagehooks --output=block
Volatile Systems Volatility Framework 2.1_alpha
Offset(V)  : 0xbc693988
Session    : 0
Desktop    : WinSta0\Default
Thread     : <any>
Filter     : WH_GETMESSAGE
Flags      : HF_ANSI, HF_GLOBAL
Procedure  : 0x1fd9
ihmod      : 1
Module     : C:\WINDOWS\system32\Dll.dll

Offset(V)  : 0xbc693988
Session    : 0
Desktop    : WinSta0\Default
Thread     : 1584 (explorer.exe 1624)
Filter     : WH_GETMESSAGE
Flags      : HF_ANSI, HF_GLOBAL
Procedure  : 0x1fd9
ihmod      : 1
Module     : C:\WINDOWS\system32\Dll.dll

Offset(V)  : 0xbc693988
Session    : 0
Desktop    : WinSta0\Default
Thread     : 252 (VMwareUser.exe 1768)
Filter     : WH_GETMESSAGE
Flags      : HF_ANSI, HF_GLOBAL
Procedure  : 0x1fd9
ihmod      : 1
Module     : C:\WINDOWS\system32\Dll.dll

moddump

Description
Dump a kernel driver to an executable file sample
Options
-D DUMP_DIR, --dump-dir=DUMP_DIR
Directory in which to dump executable files
-u, --unsafe
Bypasses certain sanity checks when creating image
-r REGEX, --regex=REGEX
Dump modules matching REGEX
-i, --ignore-case
Ignore case in pattern match
-b BASE, --base=BASE
Dump driver with BASE address (in hex)
Output example
$ python vol.py -f ~/memdump/infected.img moddump --dump-dir output/
Volatile Systems Volatility Framework 2.2
Module Base Module Name          Result
----------- -------------------- ------
0x0804d7000 ntoskrnl.exe         OK: driver.804d7000.sys
0x0806d1000 hal.dll              OK: driver.806d1000.sys
0x0f84dc000 fltMgr.sys           Error: Cannot acquire AS
0x0f8bba000 Fs_Rec.SYS           OK: driver.f8bba000.sys
0x0f8ce4000 dxgthk.sys           OK: driver.f8ce4000.sys
0x0b239b000 dump_atapi.sys       OK: driver.b239b000.sys
0x0f84fc000 atapi.sys            Error: Cannot acquire AS
0x0f877a000 Fips.SYS             OK: driver.f877a000.sys
0x0f8144000 mouhid.sys           OK: driver.f8144000.sys
[REMOVED]

modscan

Description
Scan Physical memory for _LDR_DATA_TABLE_ENTRY objects
Output example
$ python vol.py -f ~/memdump/infected.img modscan
Volatile Systems Volatility Framework 2.2
Offset(P)  Name                 Base             Size File
---------- -------------------- ---------- ---------- ----
0x01ed4508 kmixer.sys           0xb1610000    0x2b000 \SystemRoot\system32\drivers\kmixer.sys
0x02087100 rasacd.sys           0xf8b52000     0x3000 \SystemRoot\system32\DRIVERS\rasacd.sys
0x02094950 flpydisk.sys         0xf89ea000     0x5000 \SystemRoot\system32\DRIVERS\flpydisk.sys
0x020a0008 vmx_fb.dll           0xbf012000   0x19c000 \SystemRoot\System32\vmx_fb.dll
0x020b9af8 HIDPARSE.SYS         0xf8a32000     0x7000 \SystemRoot\system32\DRIVERS\HIDPARSE.SYS
0x020be820 netbios.sys          0xf876a000     0x9000 \SystemRoot\system32\DRIVERS\netbios.sys
0x020bf0e8 ndisuio.sys          0xb229b000     0x4000 \SystemRoot\system32\DRIVERS\ndisuio.sys
0x020c4ef0 HTTP.sys             0xb1777000    0x41000 \SystemRoot\System32\Drivers\HTTP.sys
0x020cda08 RDPCDD.sys           0xf8bc0000     0x2000 \SystemRoot\System32\DRIVERS\RDPCDD.sys
[REMOVED]

modules

Description
Print list of loaded modules
Options
-P, --physical-offset
Physical Offset
Output example
$ python vol.py -f ~/memdump/infected.img modules
Volatile Systems Volatility Framework 2.2
Offset(V)  Name                 Base             Size File
---------- -------------------- ---------- ---------- ----
0x823fc3a0 ntoskrnl.exe         0x804d7000   0x1f9c80 \WINDOWS\system32\ntkrnlpa.exe
0x823fc338 hal.dll              0x806d1000    0x20300 \WINDOWS\system32\hal.dll
0x823fc2d0 kdcom.dll            0xf8b9a000     0x2000 \WINDOWS\system32\KDCOM.DLL
0x823fc260 BOOTVID.dll          0xf8aaa000     0x3000 \WINDOWS\system32\BOOTVID.dll
0x823fc1f8 ACPI.sys             0xf856a000    0x2f000 ACPI.sys
0x823fc188 WMILIB.SYS           0xf8b9c000     0x2000 \WINDOWS\system32\DRIVERS\WMILIB.SYS
0x823fc120 pci.sys              0xf8559000    0x11000 pci.sys
0x823fc0b0 isapnp.sys           0xf869a000     0xa000 isapnp.sys
0x823fc040 compbatt.sys         0xf8aae000     0x3000 compbatt.sys
0x823ed008 BATTC.SYS            0xf8ab2000     0x4000 \WINDOWS\system32\DRIVERS\BATTC.SYS

mutantscan

Description
Scan for mutant objects _KMUTANT
Options
-s, --silent
Suppress less meaningful results
Output example
$ python vol.py -f ~/memdump/infected.img mutantscan
Volatile Systems Volatility Framework 2.2
Offset(P)  #Ptr #Hnd Signal Thread           CID Name
---------- ---- ---- ------ ---------- --------- ----
0x01e2ba90    1    1      1 0x00000000
0x01e2c150    2    1      1 0x00000000           RAS_MO_02
0x01e34170    1    1      1 0x00000000
0x01e3c878    2    1      1 0x00000000           jqs.exeM_1512_
0x01e3cfe0    3    2      1 0x00000000           WininetConnectionMutex
0x01e458e0    1    1      1 0x00000000
0x01eb7160    1    1      1 0x00000000
0x01ebbe28    2    1      1 0x00000000           vmtoolsd.exeM_1732_
0x01ecb7f8    1    1      1 0x00000000
0x01ed5640    2    1      0 0x81ea9da0 1364:1520 Instance1:  ESENT Performance Data Schema Version 40
0x01ed5eb8    2    1      1 0x00000000           !PrivacIE!SharedMemory!Mutex
[REMOVED]

netscan

Description
To scan for network artifacts in 32- and 64-bit Windows Vista, Windows 2008 Server and Windows 7 memory dumps, use the netscan command.
Output example
$ python vol.py -f ~/Desktop/win7_trial_64bit.raw --profile=Win7SP0x64 netscan
Volatile Systems Volatility Framework 2.1_alpha
Offset(P)  Proto    Local Address                  Foreign Address      State            Pid      Owner          Created
0xf882a30  TCPv4    0.0.0.0:135                    0.0.0.0:0            LISTENING        628      svchost.exe
0xfc13770  TCPv4    0.0.0.0:49154                  0.0.0.0:0            LISTENING        916      svchost.exe
0xfdda1e0  TCPv4    0.0.0.0:49154                  0.0.0.0:0            LISTENING        916      svchost.exe
0xfdda1e0  TCPv6    :::49154                       :::0                 LISTENING        916      svchost.exe
0x1121b7b0 TCPv4    0.0.0.0:135                    0.0.0.0:0            LISTENING        628      svchost.exe
0x1121b7b0 TCPv6    :::135                         :::0                 LISTENING        628      svchost.exe
0x11431360 TCPv4    0.0.0.0:49152                  0.0.0.0:0            LISTENING        332      wininit.exe
0x11431360 TCPv6    :::49152                       :::0                 LISTENING        332      wininit.exe
[REMOVED]

patcher

Description
Patches memory based on page scans
Warning
Notice that you will need to enable the write support and that your memory dump will be modified
Options
-x XML_INPUT, --xml-input=XML_INPUT
Input XML file for patching binaries (example given below)
<patchfile>
  <patchinfo method="pagescan" name="Some Descriptive Name">
    <constraints>
      <match offset="0x123">554433221100</match>
    </constraints>
    <patches>
      <setbytes offset="0x234">001122334455</setbytes>
    </patches>
  </patchinfo>
  <patchinfo>
    ...
  </patchinfo>
</patchfile>

printkey

Description
Print a registry key, and its subkeys and values
Options
-o HIVE_OFFSET, --hive-offset=HIVE_OFFSET
Hive offset (virtual)
-K KEY, --key=KEY
Registry Key
Output example
$ python vol.py -f ~/memdump/zeus2x4.vmem printkey --key="Software\Microsoft\Windows\CurrentVersion\Run"
Volatile Systems Volatility Framework 2.2
Legend: (S) = Stable   (V) = Volatile

----------------------------
Registry: \Device\HarddiskVolume1\Documents and Settings\Administrator\NTUSER.DAT
Key name: Run (S)
Last updated: 2010-09-09 19:56:33

Subkeys:

Values:
REG_SZ        {D9A7AA9F-6631-D3B2-E89F-56E338669386} : (S) "C:\Documents and Settings\Administrator\Application Data\Obyt\ihah.exe"
----------------------------
Registry: \Device\HarddiskVolume1\Documents and Settings\LocalService\NTUSER.DAT
Key name: Run (S)
Last updated: 2009-04-04 10:33:06

Subkeys:

Values:
----------------------------
Registry: \Device\HarddiskVolume1\WINDOWS\system32\config\default
Key name: Run (S)
Last updated: 2009-04-04 02:24:52

Subkeys:

Values:
----------------------------
Registry: \Device\HarddiskVolume1\Documents and Settings\NetworkService\NTUSER.DAT
Key name: Run (S)
Last updated: 2009-04-04 10:33:03

Subkeys:

Values:

procexedump

Description
Dump a process to an executable file sample
Options
-o OFFSET, --offset=OFFSET
EPROCESS offset (in hex) in the physical address space
-p PID, --pid=PID
Operate on these Process IDs (comma-separated)
-D DUMP_DIR, --dump-dir=DUMP_DIR
Directory in which to dump executable files
-u, --unsafe
Bypasses certain sanity checks when creating image
Output example
$ python vol.py -f ~/memdump/infected.img procexedump -p 532 --dump-dir=output/
Volatile Systems Volatility Framework 2.2
Process(V) ImageBase  Name                 Result
---------- ---------- -------------------- ------
0x81f015d0 0x00400000 vmtoolsd.exe         OK: executable.532.exe
Note
If Volatility is not able to dump a process with the -p parameter (e.g. process does not appear in the pslist output), you can try to use the -o (offset) parameter instead.

procmemdump

Description
Dump a process to an executable memory sample
Options
-o OFFSET, --offset=OFFSET
EPROCESS offset (in hex) in the physical address space
-p PID, --pid=PID
Operate on these Process IDs (comma-separated)
-D DUMP_DIR, --dump-dir=DUMP_DIR
Directory in which to dump executable files
-u, --unsafe
Bypasses certain sanity checks when creating image
Output example
$ python vol.py -f ~/memdump/infected.img procmemdump -p 532 --dump-dir=output/
Volatile Systems Volatility Framework 2.2
Process(V) ImageBase  Name                 Result
---------- ---------- -------------------- ------
0x81f015d0 0x00400000 vmtoolsd.exe         OK: executable.532.exe

pslist

Description
print all running processes by following the EPROCESS lists
Options
-o OFFSET, --offset=OFFSET
EPROCESS offset (in hex) in the physical address space
-p PID, --pid=PID
Operate on these Process IDs (comma-separated)
-P, --physical-offset
Physical Offset
Output example
$ python vol.py -f ~/tmp/infected.img pslist
Volatile Systems Volatility Framework 2.1
Offset(V)  Name                    PID   PPID   Thds     Hnds   Sess  Wow64 Start                Exit
---------- -------------------- ------ ------ ------ -------- ------ ------ -------------------- --------------------
0x823c8830 System                    4      0     58      599 ------      0
0x81e0b4b0 smss.exe                412      4      3       19 ------      0 2013-02-18 20:54:31
0x82164020 csrss.exe               772    412     12      465      0      0 2013-02-18 20:54:33
0x81eee548 winlogon.exe            796    412     21      459      0      0 2013-02-18 20:54:33
0x81f13958 services.exe            840    796     16      280      0      0 2013-02-18 20:54:33
0x821ecda0 lsass.exe               852    796     22      365      0      0 2013-02-18 20:54:33
0x81e219a0 vmacthlp.exe           1028    840      1       25      0      0 2013-02-18 20:54:33
0x81e57500 svchost.exe            1052    840     17      198      0      0 2013-02-18 20:54:34
0x81eae808 svchost.exe            1120    840     10      245      0      0 2013-02-18 20:54:34
0x82190658 svchost.exe            1364    840     81     1693      0      0 2013-02-18 20:54:34
0x82236020 svchost.exe            1412    840      6       91      0      0 2013-02-18 20:54:34
0x821687e8 svchost.exe            1504    840     13      179      0      0 2013-02-18 20:54:35
0x821e8468 spoolsv.exe            1820    840     13      145      0      0 2013-02-18 20:54:36
0x8217ac10 explorer.exe            272    212      0 --------      0      0 2013-02-18 20:54:51  2013-02-18 21:08:03
0x81dd7da0 rundll32.exe            496    272      7       81      0      0 2013-02-18 20:54:52
0x81f015d0 vmtoolsd.exe            532    272     38      563      0      0 2013-02-18 20:54:52
0x821a47e8 svchost.exe            1332    840      6      165      0      0 2013-02-18 20:55:00
0x81e693c0 svchost.exe            1428    840      3       78      0      0 2013-02-18 20:55:00
0x8219f500 jqs.exe                1512    840      8      241      0      0 2013-02-18 20:55:00
0x81e0f980 vmtoolsd.exe           1732    840      7      307      0      0 2013-02-18 20:55:00
0x81e55778 wscntfy.exe             128   1364      4       44      0      0 2013-02-18 20:55:18
0x8221cb20 TPAutoConnSvc.e        1880    840      5       99      0      0 2013-02-18 20:55:21
0x81e457f8 TPAutoConnect.e        2420   1880      4       77      0      0 2013-02-18 20:55:25
0x82166928 wmiapsrv.exe           3160    840      3      144      0      0 2013-02-18 20:58:01
0x82241518 wuauclt.exe            4012   1364      6      120      0      0 2013-02-18 21:04:15
0x81ccb020 explorer.exe            600    796     19      481      0      0 2013-02-18 21:08:05
0x81cbdb20 netsh.exe              3860    532      0 --------      0      0 2013-02-18 21:15:17  2013-02-18 21:15:18
0x81c75020 notepad.exe            3052    532      0 --------      0      0 2013-02-18 21:15:20  2013-02-18 21:15:20
0x81c20620 chrome.exe             2760    600      0 --------      0      0 2013-02-18 21:17:07  2013-02-18 21:17:44
0x81cd6630 chrome.exe             3436   2760      0 --------      0      0 2013-02-18 21:17:08  2013-02-18 21:17:18
0x81c7b308 chrome.exe             4016   2760      0 --------      0      0 2013-02-18 21:17:08  2013-02-18 21:17:44
0x81c76328 chrome.exe              460   2760      0 --------      0      0 2013-02-18 21:17:17  2013-02-18 21:17:21
0x81c211c8 chrome.exe             4088   2760      0 --------      0      0 2013-02-18 21:17:19  2013-02-18 21:17:44
0x81c88480 cmd.exe                2164    600      4       35      0      0 2013-02-18 21:17:42
0x81c6bda0 mdd_1.3.exe            2908   2164      1       28      0      0 2013-02-18 21:20:52

psscan

Description
Scan Physical memory for _EPROCESS pool allocations
Output example
$ python vol.py -f ~/memdump/infected.img psscan
Volatile Systems Volatility Framework 2.2
Offset(P)  Name                PID   PPID PDB        Time created         Time exited
---------- ---------------- ------ ------ ---------- -------------------- --------------------
0x01e20620 chrome.exe         2760    600 0x0ac80280 2013-02-18 21:17:07  2013-02-18 21:17:44
0x01e211c8 chrome.exe         4088   2760 0x0ac80300 2013-02-18 21:17:19  2013-02-18 21:17:44
0x01e6bda0 mdd_1.3.exe        2908   2164 0x0ac80260 2013-02-18 21:20:52
0x01e75020 notepad.exe        3052    532 0x0ac802c0 2013-02-18 21:15:20  2013-02-18 21:15:20
0x01e76328 chrome.exe          460   2760 0x0ac802a0 2013-02-18 21:17:17  2013-02-18 21:17:21
0x01e7b308 chrome.exe         4016   2760 0x0ac80440 2013-02-18 21:17:08  2013-02-18 21:17:44
0x01e88480 cmd.exe            2164    600 0x0ac802e0 2013-02-18 21:17:42
0x01ebdb20 netsh.exe          3860    532 0x0ac803e0 2013-02-18 21:15:17  2013-02-18 21:15:18
0x01ecb020 explorer.exe        600    796 0x0ac80460 2013-02-18 21:08:05
0x01ed6630 chrome.exe         3436   2760 0x0ac801c0 2013-02-18 21:17:08  2013-02-18 21:17:18
[REMOVED]

To visualize the processes and dependencies, you can install Graphviz and generate an image as follows:

$ python vol.py -f ~/memdump/infected.img psscan --output=dot --output-file=output/test.dot
$ dot -Tpng test.dot -o test.png

Here is an example:


pstree

Description
Print process list as a tree
Output example
$ python vol.py -f ~/tmp/infected.img pstree
Volatile Systems Volatility Framework 2.1
Name                                                  Pid   PPid   Thds   Hnds Time
-------------------------------------------------- ------ ------ ------ ------ --------------------
 0x823c8830:System                                      4      0     58    599 1970-01-01 00:00:00
. 0x81e0b4b0:smss.exe                                 412      4      3     19 2013-02-18 20:54:31
.. 0x82164020:csrss.exe                               772    412     12    465 2013-02-18 20:54:33
.. 0x81eee548:winlogon.exe                            796    412     21    459 2013-02-18 20:54:33
... 0x81ccb020:explorer.exe                           600    796     19    481 2013-02-18 21:08:05
.... 0x81c20620:chrome.exe                           2760    600      0 ------ 2013-02-18 21:17:07
..... 0x81cd6630:chrome.exe                          3436   2760      0 ------ 2013-02-18 21:17:08
..... 0x81c7b308:chrome.exe                          4016   2760      0 ------ 2013-02-18 21:17:08
..... 0x81c76328:chrome.exe                           460   2760      0 ------ 2013-02-18 21:17:17
..... 0x81c211c8:chrome.exe                          4088   2760      0 ------ 2013-02-18 21:17:19
.... 0x81c88480:cmd.exe                              2164    600      4     35 2013-02-18 21:17:42
..... 0x81c6bda0:mdd_1.3.exe                         2908   2164      1     28 2013-02-18 21:20:52
... 0x81f13958:services.exe                           840    796     16    280 2013-02-18 20:54:33
.... 0x82166928:wmiapsrv.exe                         3160    840      3    144 2013-02-18 20:58:01
.... 0x81e693c0:svchost.exe                          1428    840      3     78 2013-02-18 20:55:00
.... 0x82236020:svchost.exe                          1412    840      6     91 2013-02-18 20:54:34
.... 0x821e8468:spoolsv.exe                          1820    840     13    145 2013-02-18 20:54:36
.... 0x81e219a0:vmacthlp.exe                         1028    840      1     25 2013-02-18 20:54:33
.... 0x821a47e8:svchost.exe                          1332    840      6    165 2013-02-18 20:55:00
.... 0x821687e8:svchost.exe                          1504    840     13    179 2013-02-18 20:54:35
.... 0x81e0f980:vmtoolsd.exe                         1732    840      7    307 2013-02-18 20:55:00
.... 0x82190658:svchost.exe                          1364    840     81   1693 2013-02-18 20:54:34
..... 0x81e55778:wscntfy.exe                          128   1364      4     44 2013-02-18 20:55:18
..... 0x82241518:wuauclt.exe                         4012   1364      6    120 2013-02-18 21:04:15
.... 0x8221cb20:TPAutoConnSvc.e                      1880    840      5     99 2013-02-18 20:55:21
..... 0x81e457f8:TPAutoConnect.e                     2420   1880      4     77 2013-02-18 20:55:25
.... 0x81eae808:svchost.exe                          1120    840     10    245 2013-02-18 20:54:34
.... 0x8219f500:jqs.exe                              1512    840      8    241 2013-02-18 20:55:00
.... 0x81e57500:svchost.exe                          1052    840     17    198 2013-02-18 20:54:34
... 0x821ecda0:lsass.exe                              852    796     22    365 2013-02-18 20:54:33
 0x8217ac10:explorer.exe                              272    212      0 ------ 2013-02-18 20:54:51
. 0x81dd7da0:rundll32.exe                             496    272      7     81 2013-02-18 20:54:52
. 0x81f015d0:vmtoolsd.exe                             532    272     38    563 2013-02-18 20:54:52
.. 0x81cbdb20:netsh.exe                              3860    532      0 ------ 2013-02-18 21:15:17
.. 0x81c75020:notepad.exe                            3052    532      0 ------ 2013-02-18 21:15:20

psxview

Description
Find hidden processes with various process listings. If you see any that are "False" for pslist, psscan, and thrdproc it's an attempt to hide the process by DKOM (Direct Kernel Object Manipulation).
Options
-P, --physical-offset
Physcal Offset
Output example
$ python vol.py -f ~/memdump/infected.img psxview
Volatile Systems Volatility Framework 2.2
Offset(P)  Name                    PID pslist psscan thrdproc pspcdid csrss
---------- -------------------- ------ ------ ------ -------- ------- -----
0x0239f500 jqs.exe                1512 True   True   False    True    True
0x02057500 svchost.exe            1052 True   True   False    True    True
0x01e211c8 chrome.exe             4088 True   True   False    True    False
0x020ae808 svchost.exe            1120 True   True   False    True    True
0x0237ac10 explorer.exe            272 True   True   False    True    False
0x02113958 services.exe            840 True   True   False    True    True
0x01ebdb20 netsh.exe              3860 True   True   False    True    False
[REMOVED]
0x04c67500 svchost.exe            1052 False  True   False    False   False
0x16369c10 explorer.exe            272 False  True   False    False   False
0x0ce6c658 svchost.exe            1364 False  True   False    False   False
0x104ecb20 TPAutoConnSvc.e        1880 False  True   False    False   False
0x0f6db4b0 smss.exe                412 False  True   False    False   False
0x0867d020 notepad.exe            3052 False  True   False    False   False
0x09b60830 System                    4 False  True   False    False   False
[REMOVED]

raw2dmp

Description
Converts a physical memory sample to a windbg crash dump
Options
-b 5242880, --blocksize=5242880
Size (in bytes) of blocks to copy
-O OUTPUT_IMAGE, --output-image=OUTPUT_IMAGE
Writes a raw DD image out to OUTPUT-IMAGE
Output example
$ python vol.py -f ~/memdump/infected.img raw2dmp -O infected.dmp
Volatile Systems Volatility Framework 2.2
Writing data (5.00 MB chunks): |....................

screenshot

Description
Save a pseudo-screenshot based on GDI windows
Requires PIL

PIL first requires lib jpeg:

$ curl -O http://www.ijg.org/files/jpegsrc.v9.tar.gz
$ tar xzvf jpegsrc.v9.tar.gz
$ cd jpeg-9/
$ ./configure
$ make
$ sudo make install

Also install freetype:

$ sudo port install freetype

Then install PIL:

$ sudo pip install PIL
Output example
$ python vol.py -f ~/tmp/infected.img screenshot --dump-dir=output
Volatile Systems Volatility Framework 2.2
Wrote output/session_0.Service-0x0-3e5$.Default.png
Wrote output/session_0.SAWinSta.SADesktop.png
Wrote output/session_0.WinSta0.Default.png
Wrote output/session_0.WinSta0.Disconnect.png
Wrote output/session_0.WinSta0.Winlogon.png
Wrote output/session_0.Service-0x0-3e7$.Default.png
Wrote output/session_0.Service-0x0-3e4$.Default.png

Here is how it looks like:


sessions

Description
List details on _MM_SESSION_SPACE (user logon sessions)
Output example
$ python vol.py -f ~/memdump/infected.img sessions
Volatile Systems Volatility Framework 2.2
**************************************************
Session(V): f8bdc000 ID: 0 Processes: 26
PagedPoolStart: bb800000 PagedPoolEnd bbbfffff
 Process: 772 csrss.exe 2013-02-18 20:54:33
 Process: 796 winlogon.exe 2013-02-18 20:54:33
 Process: 840 services.exe 2013-02-18 20:54:33
 Process: 852 lsass.exe 2013-02-18 20:54:33
 Process: 1028 vmacthlp.exe 2013-02-18 20:54:33
 Process: 1052 svchost.exe 2013-02-18 20:54:34
 Process: 1120 svchost.exe 2013-02-18 20:54:34
 Process: 1364 svchost.exe 2013-02-18 20:54:34
 Process: 1412 svchost.exe 2013-02-18 20:54:34
 Process: 1504 svchost.exe 2013-02-18 20:54:35
 Process: 1820 spoolsv.exe 2013-02-18 20:54:36
 Process: 496 rundll32.exe 2013-02-18 20:54:52
[REMOVED]

shimcache

Description
Parses the Application Compatibility Shim Cache registry key
Output example
$ python vol.py -f ~/memdump/stuxnet.vmem shimcache
Volatile Systems Volatility Framework 2.2
Last Modified: 2010-10-08 03:33:07 , Lastupdate: 2010-10-08 03:33:11 , Path: \??\C:\Documents and Settings\Administrator\My Documents\Downloads\setuptools-0.6c11.win32-py2.6.exe
Last Modified: 2010-09-27 17:29:06 , Lastupdate: 2010-10-08 03:30:58 , Path: \??\C:\Documents and Settings\Administrator\Desktop\pydasm-1.5.win32-py2.6.exe
Last Modified: 2008-04-14 12:00:00 , Lastupdate: 2010-10-29 17:08:31 , Path: \??\C:\WINDOWS\system32\wscntfy.exe
Last Modified: 2008-04-14 12:00:00 , Lastupdate: 2010-10-08 04:05:22 , Path: \??\C:\WINDOWS\System32\cscui.dll
Last Modified: 2008-04-14 12:00:00 , Lastupdate: 2010-10-08 03:31:48 , Path: \??\C:\WINDOWS\system32\wuaucpl.cpl\setup50.exe
Last Modified: 2010-09-27 17:48:34 , Lastupdate: 2010-10-08 03:31:05 , Path: \??\C:\Documents and Settings\Administrator\Desktop\ssdeep-2.0-0.1.win32-py2.6.exe
Last Modified: 2008-04-14 12:00:00 , Lastupdate: 2010-10-29 16:49:28 , Path: \??\C:\WINDOWS\system32\verclsid.exe
Last Modified: 2008-04-14 12:00:00 , Lastupdate: 2010-10-29 16:49:29 , Path: \??\C:\WINDOWS\system32\SHELL32.dll
[REMOVED]

sockets

Description
Print list of open sockets
Options
-P, --physical-offset
Physical Offset
Output example
$ python vol.py -f ~/memdump/infected.img sockets
Volatile Systems Volatility Framework 2.2
Offset(V)     PID   Port  Proto Protocol        Address         Create Time
---------- ------ ------ ------ --------------- --------------- -----------
0x81ec08b0      4    137     17 UDP             192.168.1.27    2013-02-18 20:54:54
0x82295318      4      0     47 GRE             0.0.0.0         2013-02-18 21:08:01
0x81dff960    532   1291     17 UDP             0.0.0.0         2013-02-18 21:20:38
0x81efb2f0    852    500     17 UDP             0.0.0.0         2013-02-18 20:55:01
0x81c2e008    532   1224      6 TCP             0.0.0.0         2013-02-18 21:18:28
0x81c7bc58    600   1255      6 TCP             0.0.0.0         2013-02-18 21:19:25
0x81e69d08    532   1295     17 UDP             0.0.0.0         2013-02-18 21:20:40
0x81cd9c18    532   1299     17 UDP             0.0.0.0         2013-02-18 21:20:42
[REMOVED]

sockscan

Description
Scan Physical memory for _ADDRESS_OBJECT objects (tcp sockets)
Output example
$ python vol.py -f ~/memdump/infected.img sockscan
Volatile Systems Volatility Framework 2.2
Offset(P)     PID   Port  Proto Protocol        Address         Create Time
---------- ------ ------ ------ --------------- --------------- -----------
0x01e14d80   2760   1206      6 TCP             0.0.0.0         2013-02-18 21:17:31
0x01e17378   1412  41257     17 UDP             0.0.0.0         2013-02-18 21:18:32
0x01e17e98   2760   1178      6 TCP             0.0.0.0         2013-02-18 21:17:22
0x01e188d8   2760   1128      6 TCP             0.0.0.0         2013-02-18 21:17:19
0x01e1b4b8   2760   1163      6 TCP             0.0.0.0         2013-02-18 21:17:22
[REMOVED]
0x01fc94b0      4    445     17 UDP             0.0.0.0         2013-02-18 20:54:31
0x01fff960    532   1291     17 UDP             0.0.0.0         2013-02-18 21:20:38
0x02018660   1364    123     17 UDP             127.0.0.1       2013-02-18 20:55:12
0x02020e98      4    138     17 UDP             192.168.60.135  2013-02-18 20:54:39
0x02030e98   1504   1900     17 UDP             192.168.1.27    2013-02-18 20:55:25
[REMOVED]

ssdt

Description
Display SSDT entries
Output example
$ python vol.py -f ~/memdump/infected.img ssdt
Volatile Systems Volatility Framework 2.2
[x86] Gathering all referenced SSDTs from KTHREADs...
Finding appropriate address space for tables...
SSDT[0] at 80501bcc with 284 entries
  Entry 0x0000: 0x80599ade (NtAcceptConnectPort) owned by ntoskrnl.exe
  Entry 0x0001: 0x805e7784 (NtAccessCheck) owned by ntoskrnl.exe
  Entry 0x0002: 0x805eafca (NtAccessCheckAndAuditAlarm) owned by ntoskrnl.exe
  Entry 0x0003: 0x805e77b6 (NtAccessCheckByType) owned by ntoskrnl.exe
  Entry 0x0004: 0x805eb004 (NtAccessCheckByTypeAndAuditAlarm) owned by ntoskrnl.exe
  Entry 0x0005: 0x805e77ec (NtAccessCheckByTypeResultList) owned by ntoskrnl.exe
  Entry 0x0006: 0x805eb048 (NtAccessCheckByTypeResultListAndAuditAlarm) owned by ntoskrnl.exe
  Entry 0x0007: 0x805eb08c (NtAccessCheckByTypeResultListAndAuditAlarmByHandle) owned by ntoskrnl.exe
  Entry 0x0008: 0x8060c902 (NtAddAtom) owned by ntoskrnl.exe
  Entry 0x0009: 0x8060d646 (NtAddBootEntry) owned by ntoskrnl.exe
  Entry 0x000a: 0x805e2b6a (NtAdjustGroupsToken) owned by ntoskrnl.exe
  Entry 0x000b: 0x805e27c2 (NtAdjustPrivilegesToken) owned by ntoskrnl.exe
  Entry 0x000c: 0x805cb024 (NtAlertResumeThread) owned by ntoskrnl.exe
[REMOVED]

strings

Description
Match physical offsets to virtual addresses (may take a while, VERY verbose)
Requires
Requires strings file generated by Sysinternals Strings (http://technet.microsoft.com/en-us/sysinternals/bb897439).
Options
-o OFFSET, --offset=OFFSET
EPROCESS offset (in hex) in the physical address space
-s STRING_FILE, --string-file=STRING_FILE
File output in strings format (offset:string)
-S, --scan
Use PSScan if no offset is provided
-p PIDS, --pids=PIDS
Operate on these Process IDs (comma-separated)
Output example

First generate a strings file as follows (could be performed from Windows, on a Windows based VM or via Wine):

C:\> strings.exe -q -o infected.img > infected.strings.txt

Then use your file as follows:

$ python vol.py -f ~/memdump/infected.img strings -s ~/memdump/infected.strings.txt -p 532
Volatile Systems Volatility Framework 2.2
000003c1 [kernel:f83ae3c1] (,(@
00000636 [kernel:f83ae636] 8,t
000006c1 [kernel:f83ae6c1] w#r
000006d8 [kernel:f83ae6d8] sQOtN2
000006fc [kernel:f83ae6fc] t+a`"
00000719 [kernel:f83ae719] aas
0000072c [kernel:f83ae72c] Table de partition n
0000074a [kernel:f83ae74a] Erreur lors du chargement du syst
0000076c [kernel:f83ae76c] me d'exploitati
0000077c [kernel:f83ae77c] Syst
00000781 [kernel:f83ae781] me d'exploitation absent
000007b5 [kernel:f83ae7b5] ,J|'#(#
00001000 [kernel:f83af000] node_in_array != NULL
00001018 [kernel:f83af018] c:\toolchain\src\glib-2.22.4-1\glib-2.22.4\glib\gbsearcharray.h
00001058 [kernel:f83af058] file %s: line %d: assertion `%s' failed
00001080 [kernel:f83af080] Glib-GObject
00001090 [kernel:f83af090] index_ <= barray->n_nodes
000010b0 [kernel:f83af0b0] c:\toolchain\src\glib-2.22.4-1\glib-2.22.4\glib\gbsearcharray.h
000010f0 [kernel:f83af0f0] file %s: line %d: assertion `%s' failed
[REMOVED]

svcscan

Description
Scan for Windows services
Output example
$ python vol.py -f ~/memdump/infected.img svcscan
Volatile Systems Volatility Framework 2.2
Offset: 0x381e90
Order: 1
Process ID: -
Service Name: Abiosdsk
Display Name: Abiosdsk
Service Type: SERVICE_KERNEL_DRIVER
Service State: SERVICE_STOPPED
Binary Path: -

Offset: 0x381f20
Order: 2
Process ID: -
Service Name: abp480n5
Display Name: abp480n5
Service Type: SERVICE_KERNEL_DRIVER
Service State: SERVICE_STOPPED
Binary Path: -
[REMOVED]

symlinkscan

Description
Scan for symbolic link objects
Output example
$ python vol.py -f ~/memdump/infected.img symlinkscan
Volatile Systems Volatility Framework 2.2
Offset(P)    #Ptr   #Hnd Creation time            From                 To
---------- ------ ------ ------------------------ -------------------- ------------------------------------------------------------
0x02a152a0      1      0 2013-02-18 20:54:16      Scsi1:               \Device\Ide\IdePort1
0x02a16148      1      0 2013-02-18 20:54:16      VMCIDev              \Device\VMCIHostDev
0x02a16538      1      0 2013-02-18 20:54:14      Global               \GLOBAL??
0x02a16658      1      0 2013-02-18 20:54:14      GLOBALROOT
0x02a1d6c0      1      0 2013-02-18 20:54:14      DosDevices           \??
0x02a1f4b8      1      0 2013-02-18 20:54:31      SystemRoot           \Device\Harddisk0\Partition1\WINDOWS
0x02a1fe88      1      0 2013-02-18 20:54:16      Root#dmio...91efb8b} \Device\00000003
0x02a3b138      1      0 2013-02-18 20:54:17      multi(0)d...rdisk(0) \Device\Harddisk0\Partition0
0x02a51bd8      1      0 2013-02-18 20:54:16      DmLoader             \Device\DmLoader
0x02a591f0      1      0 2013-02-18 20:54:17      multi(0)d...ition(1) \Device\Harddisk0\Partition1
0x02a5b0a0      1      0 2013-02-18 20:54:15      ACPI#Fixe...9062857} \Device\0000003d
0x02a60860      1      0 2013-02-18 20:54:31      IPNAT                \Device\IPNAT
[REMOVED]

thrdscan

Description
Scan physical memory for _ETHREAD objects
Output example
$ python vol.py -f ~/memdump/spyeye.vmem thrdscan
Volatile Systems Volatility Framework 2.2
Offset(P)     PID    TID Start Address Create Time               Exit Time
---------- ------ ------ ------------- ------------------------- -------------------------
0x01eadb30   2108   2212    0x7c8106f9 2010-11-11 22:03:54
0x01eadda8   2108   2208    0x7c8106f9 2010-11-11 22:03:54
0x01eae7e0      4    584    0xb18859f0 2010-11-11 22:03:54
0x01eb2da8   1068   2636    0x7c8106f9 2011-01-06 14:36:59
0x01eb7020   1008   1824    0x7c8106f9 2010-11-11 22:03:03
0x01eba2a8   1588   1760    0x7c8106f9 2010-11-11 22:03:01
0x01eba520   1588   1756    0x7c8106f9 2010-11-11 22:03:01
0x01ebdda8   1588   1768    0x7c8106f9 2010-11-11 22:03:02
0x01ec1a78   1232   2280    0x7c8106f9 2011-01-06 14:36:52
0x01ec28b8   1252   1328    0x7c8106f9 2010-11-11 22:03:00
0x01ec2b30   1252   1320    0x7c8106f9 2010-11-11 22:03:00
0x01ec2da8   1252   1256    0x7c810705 2010-11-11 22:02:58
0x01ec4578   1068   1688    0x7c8106f9 2010-11-11 22:03:01
0x01ec4da8   1252   1332    0x7c8106f9 2010-11-11 22:03:00
0x01ec77f0    704   2252    0x7c8106f9 2011-01-06 14:36:52       2011-01-06 14:36:52
[REMOVED]

threads

Description
Investigate _ETHREAD and _KTHREADs
Options
-o OFFSET, --offset=OFFSET
EPROCESS offset (in hex) in the physical address space
-p PID, --pid=PID
Operate on these Process IDs (comma-separated)
-F FILTER, --filter=FILTER
Tags to filter (comma-separated)
-L, --listtags
List all available tags
Output example
$ python vol.py -f ~/memdump/infected.img threads -p 532
Volatile Systems Volatility Framework 2.2
[x86] Gathering all referenced SSDTs from KTHREADs...
Finding appropriate address space for tables...
------
ETHREAD: 0x821ea580 Pid: 532 Tid: 3164
Tags:
Created: 2013-02-18 20:56:05
Exited: 1970-01-01 00:00:00
Owning Process: vmtoolsd.exe
Attached Process: vmtoolsd.exe
State: Waiting:WrLpcReceive
BasePriority: 0x8
Priority: 0x9
TEB: 0x7ffdb000
StartAddress: 0x7c810729 UNKNOWN
Win32StartAddress: 0x00014fe0
ServiceTable: 0x805530e0
  [0] 0x80501bcc
  [1] 0xbf99e580
  [2] 0x00000000
  [3] 0x00000000
Win32Thread: 0xe1efceb0
CrossThreadFlags:
Eip: 0x7c91e514
  eax=0x0019ac98 ebx=0x00000000 ecx=0x001a7d48 edx=0x21380004 esi=0x0018d8b0 edi=0x0018d954
  eip=0x7c91e514 esp=0x02c2fe18 ebp=0x02c2ff80 err=0x00000000
  cs=0x1b ss=0x23 ds=0x23 es=0x23 gs=0x00 efl=0x00000246
  dr0=0x00000000 dr1=0x00000000 dr2=0x00000000 dr3=0x00000000 dr6=0x00000000 dr7=0x00000000
[REMOVED]

timers

Description
Print kernel timers and associated module DPCs
Output example
$ python vol.py -f ~/memdump/infected.img timers
Volatile Systems Volatility Framework 2.2
Offset(V)  DueTime                  Period(ms) Signaled   Routine    Module
---------- ------------------------ ---------- ---------- ---------- ------
0x81c8d268 0x80000003:0x5e3cd682             0 -          0x80534f48 ntoskrnl.exe
0x8055b380 0x00000008:0x61d9dd2a             0 -          0x80534b2a ntoskrnl.exe
0x8216a978 0x00000003:0xbe8bb404             0 -          0xb253a85a afd.sys
0x81e15f08 0x00000003:0xb9da12d4             0 -          0xb253a85a afd.sys
0x80551850 0x00000003:0xc5c5d4d4         60000 Yes        0x804f3edc ntoskrnl.exe
0x821c7c20 0x00000003:0xc10847e2             0 -          0xb253a85a afd.sys
0xb25dd1c0 0x00000003:0xcf7a2728         60000 Yes        0xb25cd471 ipsec.sys
0xb25dcd08 0x00000003:0xcf7a2728             0 -          0xb25cd3e7 ipsec.sys
0xb25dcd70 0x00000008:0x6ba60702             0 -          0xb25cd3e7 ipsec.sys
0xb2435d60 0x00000003:0xcf83b090         60000 Yes        0xb242d266 ipnat.sys
[REMOVED]

userassist

Description
Print userassist registry keys and information.
Output example
$ python vol.py -f ~/memdump/infected.img userassist
Volatile Systems Volatility Framework 2.2
----------------------------
Registry: \Device\HarddiskVolume1\Documents and Settings\pilou\NTUSER.DAT
Key name: Count
Last updated: 2013-02-18 21:17:42

Subkeys:

Values:

REG_BINARY    UEME_CTLSESSION :
0x00000000  e2 b7 6f 0e 28 00 00 00                           ..o.(...

REG_BINARY    UEME_CTLCUACount:ctor :
ID:             1
Count:          2
Last updated:   1970-01-01 00:00:00
0x00000000  01 00 00 00 02 00 00 00 00 00 00 00 00 00 00 00   ................

REG_BINARY    UEME_RUNPATH    :
ID:             40
Count:          249
Last updated:   2013-02-18 21:17:42
0x00000000  28 00 00 00 fe 00 00 00 d0 cc 4a 63 1d 0e ce 01   (.........Jc....

REG_BINARY    UEME_RUNPATH:C:\WINDOWS\system32\cmd.exe :
ID:             40
Count:          51
Last updated:   2013-02-18 21:17:42
0x00000000  28 00 00 00 38 00 00 00 d0 cc 4a 63 1d 0e ce 01   (...8.....Jc....

REG_BINARY    UEME_RUNPATH:C:\Program Files\Internet Explorer\iexplore.exe :
ID:             36
Count:          22
Last updated:   2012-12-22 14:22:12
0x00000000  24 00 00 00 1b 00 00 00 00 ea 18 bc 4f e0 cd 01   $...........O...
[REMOVED]

userhandles

Description
Dump the USER handle tables
Options
-p PID, --pid=PID
Pid filter
-t TYPE, --type=TYPE
Handle type
-F, --free
Include free handles
Output example
$ python vol.py -f ~/memdump/infected.img userhandles -p 532
Volatile Systems Volatility Framework 2.2
**************************************************
SharedInfo: 0xbf9af820, SessionId: 0 Shared delta: 0
aheList: 0xbbd10000, Table size: 0x2000, Entry size: 0xc

Object(V)      Handle bType                 Flags    Thread  Process
---------- ---------- -------------------- -------- -------- -------
0xbbe6dc40   0x2d003f TYPE_INPUTCONTEXT       0       3340   532
0xbbe3e7a0    0x200a0 TYPE_HOOK               0       536    532
0xbbe55cb8  0x20d00a1 TYPE_INPUTCONTEXT       0       2680   532
0xbbe3b190    0x200a6 TYPE_WINDOW             0       536    532
0xbbe3afd8    0x200a8 TYPE_WINDOW             0       536    532
0xbbe3af10    0x200aa TYPE_WINDOW             0       536    532
0xbbe3ad80    0x200ac TYPE_WINDOW             0       536    532
0xbbe3ac00    0x200ae TYPE_WINDOW             0       536    532
0xbbe3aae8    0x200b0 TYPE_WINDOW             0       536    532
0xbbe5bad8    0x200b2 TYPE_WINDOW             0       536    532
0xbbe3b270    0x200b6 TYPE_WINDOW             0       536    532
0xbbe46d78    0x300cb TYPE_INPUTCONTEXT       0       536    532
0xbbe3e830    0x20102 TYPE_WINDOW             0       536    532
0xbbe3d668    0xc0108 TYPE_WINDOW             0       536    532
[REMOVED]

vaddump

Description
Dumps out the vad sections to a file
Options
-o OFFSET, --offset=OFFSET
EPROCESS offset (in hex) in the physical address space
-p PID, --pid=PID
Operate on these Process IDs (comma-separated)
-D DUMP_DIR, --dump-dir=DUMP_DIR
Directory in which to dump the VAD files
Output example
$ python vol.py -f ~/memdump/infected.img vaddump -p 532 -D output/
Volatile Systems Volatility Framework 2.2
Pid        Process              Start      End        Result
---------- -------------------- ---------- ---------- ------
       532 vmtoolsd.exe         0x05270000 0x0536ffff output/vmtoolsd.exe.21015d0.0x05270000-0x0536ffff.dmp
       532 vmtoolsd.exe         0x03140000 0x04172fff output/vmtoolsd.exe.21015d0.0x03140000-0x04172fff.dmp
       532 vmtoolsd.exe         0x022e0000 0x022e0fff output/vmtoolsd.exe.21015d0.0x022e0000-0x022e0fff.dmp
       532 vmtoolsd.exe         0x02090000 0x02090fff output/vmtoolsd.exe.21015d0.0x02090000-0x02090fff.dmp
       532 vmtoolsd.exe         0x01f50000 0x0204ffff output/vmtoolsd.exe.21015d0.0x01f50000-0x0204ffff.dmp
       532 vmtoolsd.exe         0x01ef0000 0x01efdfff output/vmtoolsd.exe.21015d0.0x01ef0000-0x01efdfff.dmp
       532 vmtoolsd.exe         0x01470000 0x01d9afff output/vmtoolsd.exe.21015d0.0x01470000-0x01d9afff.dmp
[REMOVED]

vadinfo

Description
Dump the VAD info
Options
-o OFFSET, --offset=OFFSET
EPROCESS offset (in hex) in the physical address space
-p PID, --pid=PID
Operate on these Process IDs (comma-separated)
Output example
$ python vol.py -f ~/memdump/infected.img vadinfo -p 532
Volatile Systems Volatility Framework 2.2
************************************************************************
Pid:    532
VAD node @ 0x81cd22b0 Start 0x05270000 End 0x0536ffff Tag VadS
Flags: CommitCharge: 2, PrivateMemory: 1, Protection: 4
Protection: PAGE_READWRITE

VAD node @ 0x81e06320 Start 0x03140000 End 0x04172fff Tag VadS
Flags: CommitCharge: 4147, MemCommit: 1, PrivateMemory: 1, Protection: 6
Protection: PAGE_EXECUTE_READWRITE

VAD node @ 0x81ecdaa8 Start 0x022e0000 End 0x022e0fff Tag Vadl
Flags: CommitCharge: 1, MemCommit: 1, NoChange: 1, PrivateMemory: 1, Protection: 4
Protection: PAGE_READWRITE
First prototype PTE: 00000000 Last contiguous PTE: 00000000
Flags2: LongVad: 1, OneSecured: 1

VAD node @ 0x81ec33d8 Start 0x02090000 End 0x02090fff Tag VadS
Flags: CommitCharge: 1, PrivateMemory: 1, Protection: 4
Protection: PAGE_READWRITE
[REMOVED]

vadtree

Description
Walk the VAD tree and display in tree format
Options
-o OFFSET, --offset=OFFSET
EPROCESS offset (in hex) in the physical address space
-p PID, --pid=PID
Operate on these Process IDs (comma-separated)
Output example
$ python vol.py -f ~/memdump/infected.img vadtree -p 532
Volatile Systems Volatility Framework 2.2
************************************************************************
Pid:    532
 0x05270000 - 0x0536ffff
  0x03140000 - 0x04172fff
   0x022e0000 - 0x022e0fff
    0x02090000 - 0x02090fff
     0x01f50000 - 0x0204ffff
      0x01ef0000 - 0x01efdfff
       0x01470000 - 0x01d9afff
        0x00f40000 - 0x00f40fff
         0x00e10000 - 0x00e4ffff
          0x00900000 - 0x00bfffff
           0x00400000 - 0x00410fff
            0x00030000 - 0x0012ffff
             0x00010000 - 0x00010fff
              0x00020000 - 0x00020fff
             0x00140000 - 0x00140fff
              0x00130000 - 0x00132fff
              0x00250000 - 0x0025ffff
[REMOVED]

vadwalk

Description
Walk the VAD tree
Options
-o OFFSET, --offset=OFFSET
EPROCESS offset (in hex) in the physical address space
-p PID, --pid=PID
Operate on these Process IDs (comma-separated)
$ python vol.py -f ~/memdump/infected.img vadwalk -p 532
Volatile Systems Volatility Framework 2.2
************************************************************************
Pid:    532
Address    Parent     Left       Right      Start      End        Tag
---------- ---------- ---------- ---------- ---------- ---------- ----
0x81cd22b0 0x00000000 0x81e06320 0x81f01d90 0x05270000 0x0536ffff VadS
0x81e06320 0x81cd22b0 0x81ecdaa8 0x8227c3e8 0x03140000 0x04172fff VadS
0x81ecdaa8 0x81e06320 0x81ec33d8 0x81f43938 0x022e0000 0x022e0fff Vadl
0x81ec33d8 0x81ecdaa8 0x81e05040 0x822008f8 0x02090000 0x02090fff VadS
0x81e05040 0x81ec33d8 0x823195b0 0x81e53b70 0x01f50000 0x0204ffff VadS
0x823195b0 0x81e05040 0x82171b18 0x8220b768 0x01ef0000 0x01efdfff Vad
0x82171b18 0x823195b0 0x821d2a78 0x82229ea8 0x01470000 0x01d9afff Vad
0x821d2a78 0x82171b18 0x8215b788 0x81e5ec00 0x00f40000 0x00f40fff Vad
0x8215b788 0x821d2a78 0x81f06870 0x822e1ed8 0x00e10000 0x00e4ffff Vad
[REMOVED]

volshell

Description
Interactive shell to explore a memory image, offering an interface similar to WinDbg:
  • List processes
  • Switch into a process's context
  • Display types of structures/objects
  • Overlay a type over a given address
  • Walk linked lists
  • Disassemble code at a given address
Options
-o OFFSET, --offset=OFFSET
EPROCESS Offset (in hex) in kernel address space
-n IMNAME, --imname=IMNAME
Operate on these Process IDs (comma-separated)
-p PID, --pid=PID
Operate on these Process IDs (comma-separated)
Output example
$ python vol.py -f ~/memdump/infected.img volshell
Volatile Systems Volatility Framework 2.2
Current context: process System, pid=4, ppid=0 DTB=0x31e000
Welcome to volshell! Current memory image is:
file:///Users/sebastiendamaye/memdump/infected.img
To get help, type 'hh()'
>>> hh()
ps()                                     : Print a process listing.
dq(address, length=128, space=None)      : Print qwords at address.
cc(offset=None, pid=None, name=None)     : Change current shell context.
dd(address, length=128, space=None)      : Print dwords at address.
list_entry(head, objname, offset=-1, fieldname=None, forward=True) : Traverse a _LIST_ENTRY.
db(address, length=128, space=None)      : Print bytes as canonical hexdump.
dt(objct, address=None, address_space=None) : Describe an object or show type info.
hh(cmd=None)                             : Get help on a command.
dis(address, length=128, space=None, mode=None) : Disassemble code at a given address.

For help on a specific command, type 'hh(<command>)'
>>> ps()
Name             PID    PPID   Offset
System           4      0      0x823c8830
smss.exe         412    4      0x81e0b4b0
csrss.exe        772    412    0x82164020
winlogon.exe     796    412    0x81eee548
services.exe     840    796    0x81f13958
lsass.exe        852    796    0x821ecda0
vmacthlp.exe     1028   840    0x81e219a0
svchost.exe      1052   840    0x81e57500
svchost.exe      1120   840    0x81eae808
svchost.exe      1364   840    0x82190658
svchost.exe      1412   840    0x82236020
[REMOVED]

windows

Description
Print Desktop Windows (verbose details)
Output example
$ python vol.py -f ~/memdump/infected.img windows
Volatile Systems Volatility Framework 2.2
**************************************************
Window context: 0\SAWinSta\SADesktop

Window Handle: #10020 at 0xbc130818, Name:
ClassAtom: 0xc035, Class: msctls_progress32
SuperClassAtom: 0xc035, SuperClass: msctls_progress32
pti: 0xe16ef510, Tid: 860 at 0x821e66e8
ppi: 0xe199b008, Process: csrss.exe, Pid: 772
Visible: No
Left: 0, Top: 0, Bottom: 100, Right: 100
Style Flags: WS_CLIPCHILDREN,WS_OVERLAPPED,WS_POPUP,WS_CLIPSIBLINGS
ExStyle Flags: WS_EX_LTRREADING,WS_EX_RIGHTSCROLLBAR,WS_EX_LEFT
Window procedure: 0xbf80d28d

Window Handle: #10022 at 0xbc130940, Name:
ClassAtom: 0x8000, Class: -
SuperClassAtom: 0x8000, SuperClass: -
pti: 0xe16ef510, Tid: 860 at 0x821e66e8
ppi: 0xe199b008, Process: csrss.exe, Pid: 772
Visible: No
Left: 3, Top: 3, Bottom: 97, Right: 97
Style Flags: WS_BORDER,WS_OVERLAPPED,WS_POPUP,WS_CLIPSIBLINGS
ExStyle Flags: WS_EX_LTRREADING,WS_EX_TOOLWINDOW,WS_EX_RIGHTSCROLLBAR,WS_EX_DLGMODALFRAME,WS_EX_WINDOWEDGE,WS_EX_LEFT
Window procedure: 0xbf860ffc
[REMOVED]

wintree

Description
Print Z-Order Desktop Windows Tree
Output example
$ python vol.py -f ~/memdump/infected.img wintree
Volatile Systems Volatility Framework 2.2
**************************************************
Window context: 0\SAWinSta\SADesktop

#10020  csrss.exe:772 msctls_progress32
.#10022  csrss.exe:772 -
.OleMainThreadWndName  svchost.exe:1364 msctls_hotkey32
#1001e  csrss.exe:772 -
.#6016c  svchost.exe:1364 Tapi32WndClass
.SYSTEM AGENT COM WINDOW  svchost.exe:1364 SAGEWINDOWCLASS
.internal window  svchost.exe:1364 Bits
.BadApplicationNotificationWindow  svchost.exe:1364 BadApplicationNotificationWindowClass
.ModemDeviceChange  svchost.exe:1364 MdmDevChg
.#401d6  svchost.exe:1364 HidPhoneNotifClass
#1002c  csrss.exe:772 msctls_progress32
.#1002e  csrss.exe:772 -
#2002a  csrss.exe:772 -
#10032  csrss.exe:772 msctls_progress32
.#10034  csrss.exe:772 -
#20030  csrss.exe:772 -
.#100fc  svchost.exe:1428 BthServClass
#1006c  csrss.exe:772 msctls_progress32
.#1006e  csrss.exe:772 -
#5006a  csrss.exe:772 -
[REMOVED]

wndscan

Description
Pool scanner for tag WINDOWSTATION (window stations)
Output example
$ python vol.py -f ~/memdump/infected.img wndscan
Volatile Systems Volatility Framework 2.2
**************************************************
WindowStation: 0x205c318, Name: Service-0x0-3e5$, Next: 0x81f03ce8
SessionId: 0, AtomTable: 0xe19b3c18, Interactive: False
Desktops: Default
ptiDrawingClipboard: pid - tid -
spwndClipOpen: 0x0, spwndClipViewer: 0x0
cNumClipFormats: 0, iClipSerialNumber: 0
pClipBase: 0x0, Formats:
**************************************************
WindowStation: 0x2103ce8, Name: SAWinSta, Next: 0x0
SessionId: 0, AtomTable: 0xe1ee5278, Interactive: False
Desktops: SADesktop
ptiDrawingClipboard: pid - tid -
spwndClipOpen: 0x0, spwndClipViewer: 0x0
cNumClipFormats: 0, iClipSerialNumber: 0
pClipBase: 0x0, Formats:
[REMOVED]

yarascan

Description
Scan process or kernel memory with Yara signatures
Requires
Yara (http://code.google.com/p/yara-project/)
Options
-o OFFSET, --offset=OFFSET
EPROCESS offset (in hex) in the physical address space
-p PID, --pid=PID
Operate on these Process IDs (comma-separated)
-K, --kernel
Scan kernel modules
-W, --wide
Match wide (unicode) strings
-Y YARA_RULES, --yara-rules=YARA_RULES
Yara rules (as a string)
-y YARA_FILE, --yara-file=YARA_FILE
Yara rules (rules file)
-D DUMP_DIR, --dump-dir=DUMP_DIR
Directory in which to dump the files
Output example

Let's create a yara signature as follows:

$ cat ~/pentest/yara-sigs/sality.yara
rule sality
{
strings:
    $a = "mirc1.net"
    $b = "elaswany.com"
    $c = "logos.gif"
condition:
    any of them
}

Let's identify process matching the yard signature;

$ python vol.py -f ~/memdump/infected.img yarascan -y ~/pentest/yara-sigs/sality.yara
Volatile Systems Volatility Framework 2.2
Rule: sality
Owner: Process vmtoolsd.exe Pid 532
0x0315919d  6d 69 72 63 31 2e 6e 65 74 2f 6c 6f 67 6f 73 2e   mirc1.net/logos.
0x031591ad  67 69 66 00 68 74 74 70 3a 2f 2f 77 77 77 2e 64   gif.http://www.d
0x031591bd  6f 67 75 73 2d 70 6c 61 73 74 69 6b 2e 63 6f 6d   ogus-plastik.com
0x031591cd  2f 6c 6f 67 6f 73 2e 67 69 66 00 68 74 74 70 3a   /logos.gif.http:
Rule: sality
Owner: Process vmtoolsd.exe Pid 532
0x031591a7  6c 6f 67 6f 73 2e 67 69 66 00 68 74 74 70 3a 2f   logos.gif.http:/
0x031591b7  2f 77 77 77 2e 64 6f 67 75 73 2d 70 6c 61 73 74   /www.dogus-plast
0x031591c7  69 6b 2e 63 6f 6d 2f 6c 6f 67 6f 73 2e 67 69 66   ik.com/logos.gif
0x031591d7  00 68 74 74 70 3a 2f 2f 6d 61 63 65 64 6f 6e 69   .http://macedoni
Rule: sality
Owner: Process vmtoolsd.exe Pid 532
0x031591ce  6c 6f 67 6f 73 2e 67 69 66 00 68 74 74 70 3a 2f   logos.gif.http:/
0x031591de  2f 6d 61 63 65 64 6f 6e 69 61 2e 6d 79 31 2e 72   /macedonia.my1.r
0x031591ee  75 2f 6d 61 69 6e 68 2e 67 69 66 00 68 74 74 70   u/mainh.gif.http
0x031591fe  3a 2f 2f 67 69 7a 61 65 64 75 2e 6f 72 67 2f 6d   ://gizaedu.org/m
[REMOVED]

Examples

Comments

blog comments powered by Disqus
